2017 Caterpillar 313D
Product Description
Powered by a robust Cat C4.2 ACERT engine delivering 67 kW of net power, this 2017 Caterpillar 313D compact excavator combines proven reliability with exceptional value. Operating at 13 tons working weight, it offers 82 kN bucket digging force and a maximum digging depth of 5,580 mm—ideal for urban construction, utility work, and medium-duty excavation projects. With a 0.52 m³ bucket capacity and 8,220 mm maximum reach, productivity remains consistently high across diverse jobsites.
Key Performance Specifications:
- Cat C4.2 ACERT 4-cylinder diesel engine (4.25L displacement, water-cooled)
- Maximum digging reach: 8,220 mm; unloading height: 6,060 mm
- Hydraulic system: 127 L/min main pump flow at 30.5 MPa
- Compact transport dimensions: 7,610 mm × 2,490 mm × 2,830 mm
- Meets US EPA Tier 3 and EU Stage IIIA emission standards
Currently located in Huizhou, Guangdong, this joint-venture manufactured unit delivers performance comparable to new machines at a fraction of the investment. Smart buyers recognize the 313D's reputation for durability and low operating costs—making it an intelligent choice for contractors seeking maximum return without new equipment
| Specifications | Value |
|---|---|
| No. | 1041626 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13430 |
| Bucket capacity (m³) | 0.52 |
| Boom length (mm) | 4650 |
| Rod length (mm) | 2500 |
| Country of origin | Xuzhou, Jiangsu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar Cat C4.2 ACERT |
| Rated power (kw/rpm) | 67 (Net power) |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.25 |
| Working form | Meets the emission requirements of US EPA Tier 3 and European IIIA Directive 97/68/EC. |
| Ground specific pressure (Kpa) | 41.8 (with 500mm track plate) |
| Rotation speed (rpm) | 12.4 |
| Bucket digging force (kN) | 82 |
| Rod digging force (kN) | 63 |
| Maximum tractive force (kN) | 114 |
| Travel speed (km/h) | 5.5 |
| Main overflow set pressure (Mpa) | 30.5 |
| Maximum flow of main pump (l/min) | 127 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Pilot Oil Circuit (MPa) | 41.2 |
| Pilot pump flow (L/min) | 21.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 100 x 939 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 120 x 1197 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 110 x 1015 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 19.5 |
| Coolant (L) | 17.9 |
| Hydraulic System (L) | 162 (including fuel tank) |
| Total transport length (mm) | 7610 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2830 (to top of boom) |
| Full cab height (mm) | 2760 |
| Counterweight ground clearance (mm) | 915 |
| Minimum ground clearance (mm) | 430 |
| Back end turning radius (mm) | 2140 |
| Total track length (mm) | 3490 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 (standard) |
| Total track width (mm) | 2490 |
| Maximum digging depth (mm) | 5580 |
| Maximum unloading height (mm) | 6060 |
| Maximum vertical digging depth (mm) | 5040 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 8220 |
| Boom turning Angle (left/right °) | There is no |
| Maximum effective digging depth (mm) | 5380 |
