2018 Caterpillar 313D
Product Description
Available now from our Wenzhou, Zhejiang facility, this 2018 Caterpillar 313D mini excavator delivers immediate deployment without factory lead times. Powered by the reliable Cat C4.2 ACERT engine producing 67 kW, this 13-ton machine combines proven Caterpillar engineering with ready-to-ship availability for projects demanding fast mobilization.
Equipped with a 0.52 m³ bucket, 4650mm boom, and 2500mm arm, this excavator reaches a maximum digging depth of 5580mm and excavation radius of 8220mm. Hydraulic performance includes 82 kN bucket digging force and 63 kN arm digging force, supported by a 127 L/min main pump flow at 30.5 MPa system pressure. The water-cooled 4-cylinder engine meets US EPA Tier 3 and EU Stage IIIA emissions standards.
Key specifications for rapid site integration:
- Operating weight: 13,430 kg with standard 500mm track plates
- Compact transport dimensions: 7610mm L × 2490mm W × 2830mm H
- Travel speed: 5.5 km/h with 114 kN maximum tractive effort
- Fuel capacity: 250L for extended runtime
- Ground pressure: 41.8 kPa minimizes surface disturbance
Skip months of factory waiting. Inspect in Wenzhou and arrange shipping to your location immediate
| Specifications | Value |
|---|---|
| No. | 1036923 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13430 |
| Bucket capacity (m³) | 0.52 |
| Boom length (mm) | 4650 |
| Rod length (mm) | 2500 |
| Country of origin | Xuzhou, Jiangsu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar Cat C4.2 ACERT |
| Rated power (kw/rpm) | 67 (Net power) |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.25 |
| Working form | Meets the emission requirements of US EPA Tier 3 and European IIIA Directive 97/68/EC. |
| Ground specific pressure (Kpa) | 41.8 (with 500mm track plate) |
| Rotation speed (rpm) | 12.4 |
| Bucket digging force (kN) | 82 |
| Rod digging force (kN) | 63 |
| Maximum tractive force (kN) | 114 |
| Travel speed (km/h) | 5.5 |
| Main overflow set pressure (Mpa) | 30.5 |
| Maximum flow of main pump (l/min) | 127 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Pilot Oil Circuit (MPa) | 41.2 |
| Pilot pump flow (L/min) | 21.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 100 x 939 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 120 x 1197 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 110 x 1015 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 19.5 |
| Coolant (L) | 17.9 |
| Hydraulic System (L) | 162 (including fuel tank) |
| Total transport length (mm) | 7610 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2830 (to top of boom) |
| Full cab height (mm) | 2760 |
| Counterweight ground clearance (mm) | 915 |
| Minimum ground clearance (mm) | 430 |
| Back end turning radius (mm) | 2140 |
| Total track length (mm) | 3490 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 (standard) |
| Total track width (mm) | 2490 |
| Maximum digging depth (mm) | 5580 |
| Maximum unloading height (mm) | 6060 |
| Maximum vertical digging depth (mm) | 5040 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 8220 |
| Boom turning Angle (left/right °) | There is no |
| Maximum effective digging depth (mm) | 5380 |
