2019 Caterpillar 313D
Product Description
Strengthen your fleet capacity with this 2019 Caterpillar 313D excavator, a 13-ton workhorse engineered for contractors managing multiple job sites simultaneously. Powered by the reliable Cat C4.2 ACERT engine delivering 67 kW net power, this machine meets US EPA Tier 3 and European IIIA emission standards while maintaining consistent performance across demanding applications. Currently located in Shaoxing, Zhejiang, this unit offers immediate availability to expand your operational reach.
Built for versatility, the 313D features a 0.52 m³ bucket capacity with 82 kN digging force and 5,580 mm maximum digging depth. Its compact 2,140 mm tail swing radius enables efficient operation in confined urban sites, while the 8,220 mm maximum reach handles larger excavation tasks. The water-cooled engine and 127 L/min hydraulic flow ensure reliable all-day productivity whether deployed as primary equipment or backup support during peak demand periods.
- Working weight: 13,430 kg with optimal 41.8 kPa ground pressure
- Boom/arm configuration: 4,650 mm / 2,500 mm for balanced reach and depth
- Transport dimensions: 7,610 mm (L) × 2,490 mm (W) × 2,830 mm (H)
- Fuel capacity: 250 L for extended shifts witho
| Specifications | Value |
|---|---|
| No. | 1050558 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13430 |
| Bucket capacity (m³) | 0.52 |
| Boom length (mm) | 4650 |
| Rod length (mm) | 2500 |
| Country of origin | Xuzhou, Jiangsu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar Cat C4.2 ACERT |
| Rated power (kw/rpm) | 67 (Net power) |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Number of cylinders (PCS) | 4 |
| Displacement (L) | 4.25 |
| Working form | Meets the emission requirements of US EPA Tier 3 and European IIIA Directive 97/68/EC. |
| Ground specific pressure (Kpa) | 41.8 (with 500mm track plate) |
| Rotation speed (rpm) | 12.4 |
| Bucket digging force (kN) | 82 |
| Rod digging force (kN) | 63 |
| Maximum tractive force (kN) | 114 |
| Travel speed (km/h) | 5.5 |
| Main overflow set pressure (Mpa) | 30.5 |
| Maximum flow of main pump (l/min) | 127 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 23 |
| Pilot Oil Circuit (MPa) | 41.2 |
| Pilot pump flow (L/min) | 21.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 100 x 939 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 120 x 1197 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 110 x 1015 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 150 |
| Engine Oil changes (L) | 19.5 |
| Coolant (L) | 17.9 |
| Hydraulic System (L) | 162 (including fuel tank) |
| Total transport length (mm) | 7610 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2830 (to top of boom) |
| Full cab height (mm) | 2760 |
| Counterweight ground clearance (mm) | 915 |
| Minimum ground clearance (mm) | 430 |
| Back end turning radius (mm) | 2140 |
| Total track length (mm) | 3490 |
| Track gauge (mm) | 1990 |
| Track plate width (mm) | 500 (standard) |
| Total track width (mm) | 2490 |
| Maximum digging depth (mm) | 5580 |
| Maximum unloading height (mm) | 6060 |
| Maximum vertical digging depth (mm) | 5040 |
| Bulldozer lift or depth (mm) | There is no |
| Dodging plate width × height (mm) | There is no |
| Maximum excavation radius of stop surface (mm) | 8220 |
| Boom turning Angle (left/right °) | There is no |
| Maximum effective digging depth (mm) | 5380 |
