2016 Caterpillar 313D2
Product Description
Built to endure the toughest job sites, this 2016 Caterpillar 313D2 mini hydraulic excavator represents proven engineering excellence. With years of reliable operation already logged, this machine demonstrates the legendary durability Caterpillar is known for worldwide. Currently located in Jiangxi Ji'an, it stands ready to deliver consistent performance for demanding excavation, trenching, and material handling applications.
Compact dimensions combined with robust construction make this 313D2 an ideal workhorse for urban construction, utility work, and confined-space projects. Its hydraulic system delivers precise control and efficient power management, reducing fuel consumption while maintaining productivity. Operators benefit from responsive controls and excellent visibility, ensuring safe, efficient operation across multiple shifts.
- Year: 2016 - Proven track record of reliability
- Model: Caterpillar 313D2 Mini Hydraulic Excavator
- Location: Jiangxi Ji'an, China
- Legendary Caterpillar durability and parts availability
- Compact footprint for versatile job site deployment
Invest in equipment that has already proven its worth. Contact Fair Trade Machinery today for
| Specifications | Value |
|---|---|
| No. | 1016804 |
| Tonnage (tons) | 13 |
| Working weight (kg) | 13400 |
| Bucket capacity (m³) | 0.65 |
| Country of origin | Xuzhou, Jiangsu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | 3054C |
| Rated power (kw/rpm) | 70 |
| Cylinder diameter × stroke (mm) | 105 x 127 |
| Displacement (L) | 4.4 |
| Rotation speed (rpm) | 12.2 |
| Bucket digging force (kN) | 95KN |
| Rod digging force (kN) | 65KN |
| Maximum tractive force (kN) | 114 |
| Travel speed (km/h) | 5.6 |
| Turning torque (Nm) | 30.9 |
| Maximum flow of main pump (l/min) | 254 |
| Bucket cylinders - Number × diameter × stroke (mm) | 100 x 939 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 120 x 1197 |
| Boom cylinders - Number × diameter × stroke (mm) | 110 x 1015 |
| Fuel Tank (L) | 250 |
| Hydraulic Tank (L) | 90.6 |
| Engine Oil changes (L) | 16 |
| Coolant (L) | 17.88 |
| Total transport length (mm) | 7610 |
| Total transport width (mm) | 2490 |
| Total transport height (mm) | 2830 |
| Full cab height (mm) | 2670 |
| Counterweight ground clearance (mm) | 900 |
| Minimum ground clearance (mm) | 440 |
| Back end turning radius (mm) | 2140 |
| Total track length (mm) | 3490 |
| Track gauge (mm) | 1990 |
| Maximum digging depth (mm) | 5580 |
| Maximum excavation height (mm) | 8510 |
| Maximum unloading height (mm) | 6060 |
| Maximum vertical digging depth (mm) | 5050 |
| Maximum effective digging depth (mm) | 5370 |
Overview
No.1016804
Brand Name：
CaterpillarModel Number：
313D2Year：
2016
Location：
Jiangxi China
