Name: Used Excavators 2009 Caterpillar 320C
Brand: Caterpillar
SKU: USED-1045157
Availability: InStock
Rating: 4.5 (71 reviews)

Sany

Caterpillar

XCMG

Hitachi

Komatsu

Doosan

Kobelco

Hyundai

Volvo

Sumitomo

Kato

Case

Yanmar

JohnDeere

Liebherr

Built for demanding jobsites, this 2009 Caterpillar 320C medium excavator delivers 20-ton performance with operator-focused engineering. Powered by a reliable CAT 3066 ATAAC engine producing 110 kW at 1800 rpm, this machine combines hydraulic precision with field-proven durability. The water-cooled 6.4L engine ensures consistent power delivery across extended work cycles.

Operators benefit from superior visibility and responsive controls in the spacious cab, positioned 3050 mm above ground for commanding sightlines. Hydraulic flow reaches 205 l/min through the main pump, enabling smooth simultaneous functions. The 0.8 m³ bucket generates 132 kN digging force, while the 5680 mm boom and 2900 mm arm provide a maximum reach of 9710 mm and digging depth of 6550 mm.

<ul>
<li>Working weight: 21,115 kg with optimal ground pressure of 48.02 kPa</li>
<li>Stable 2800 mm track width with 600 mm grouser plates</li>
<li>34.3 MPa working hydraulic circuit for consistent performance</li>
<li>320L fuel capacity for extended operation</li>
<li>Currently located in Maoming, Guangdong Province</li>
</ul>

Skip the factory lead times with this ready-to-deploy 2016 Komatsu PC120 excavator, strategically positioned in Hubei Province for immediate delivery across China. Built with Japanese precision engineering, this 12-ton workhorse delivers reliable performance through its proven Komatsu S4D105-5 engine producing 67.1kW of power.

Engineered for versatility, this machine combines a 4.6-meter boom with a 2.0-meter arm to achieve maximum digging depths of 5 meters and excavation heights reaching 7.55 meters. With its compact 2.43-meter transport width and efficient hydraulic system flowing 323 L/min, rapid site deployment becomes seamless.

<ul>
<li>Available now from Hubei - no manufacturing delays</li>
<li>12-ton operating weight with 70% climbing capability</li>
<li>Maximum excavation radius: 7.54 meters</li>
<li>Fuel-efficient 230L tank capacity</li>
<li>Fast deployment ready for immediate productivity</li>
</ul>

Secure this proven performer today and maintain project momentum without the typical procurement delays associated with new equipment orders.

Komatsu PC120

Built for demanding construction environments, this 2012 Volvo EC210B excavator delivers proven performance with 21-ton operating capacity and robust Volvo D6D engine producing 107kW of reliable power. Currently located in Hubei Province, this machine features a 0.9-0.92m³ bucket capacity and impressive 9.94m maximum digging radius, making it ideal for medium to large-scale earthmoving projects.

Volvo's reputation for engineering excellence translates directly into lower ownership costs and superior resale value. Key advantages include:

<ul>
<li>Extensive parts network across China ensures minimal downtime</li>
<li>Proven hydraulic system with dual 200L/min pumps for consistent performance</li>
<li>Advanced turbocharging and electronic fuel injection for fuel efficiency</li>
<li>70% climbing ability and 183kN maximum tractive force for challenging terrain</li>
</ul>

With Volvo's established service infrastructure and strong brand recognition, this EC210B represents a smart investment for contractors seeking dependable equipment with predictable maintenance costs and strong market value retention.

Volvo EC210B

With a 30-ton capacity, the 2016 Kato HD1430 is a robust backhoe loader designed for immediate deployment in digging, grading, and demolition tasks. Built by a joint venture/import manufacturer, this machine combines traditional power with reliable performance, ensuring it’s site-ready from the moment of delivery. Located in Zhejiang Wenzhou, this excavator is equipped to handle demanding construction environments, offering durability and efficiency on every job. Whether you need to clear land or prepare foundations, the Kato HD1430 stands ready to meet your project's needs.

Kato HD1430

Built for demanding excavation and grading work, this 37-ton hydraulic excavator delivers proven performance across construction and demolition sites. The 2022 XCMG XE370 arrives from Wenzhou, Zhejiang with factory-standard traditional power systems and a backhoe bucket configuration designed for immediate deployment. Engineered in China to XCMG's manufacturing standards, this machine handles trenching, foundation work, material handling, and site preparation without modification.

<ul>
 <li>Operating Weight: 37 tons – ideal for medium to heavy-duty applications</li>
 <li>Power System: Traditional diesel engine for reliable fuel availability worldwide</li>
 <li>Bucket Type: Backhoe configuration for versatile digging and loading tasks</li>
 <li>Condition: 2022 model year with low operational hours</li>
 <li>Origin: Made in China by XCMG, a leading heavy equipment manufacturer</li>
 <li>Current Location: Wenzhou, Zhejiang Province – ready for inspection and shipping</li>
</ul>

Contractors seeking a dependable excavator for earthmoving, demolition, or infrastructure projects will find this XE370 capable of handling daily

XCMG XE370

Built for precision and durability, this 2016 Caterpillar 320A excavator delivers reliable performance across demanding job sites. Operating at 20 tons with traditional power configuration, this joint venture/import model combines proven engineering with operator-centered design. Currently located in Wenzhou, Zhejiang, this machine offers excellent value for contractors seeking dependable mid-sized excavation capacity.

Operator advantages include:
<ul>
<li>Enhanced cabin visibility for superior site awareness and safety during complex maneuvers</li>
<li>Responsive hydraulic controls providing smooth, predictable handling across varied terrain</li>
<li>Stable platform design minimizing vibration and fatigue during extended shifts</li>
<li>Backhoe configuration optimized for trenching, loading, and general excavation tasks</li>
<li>Ergonomic control layout reducing operator strain and improving productivity</li>
</ul>

With Caterpillar's reputation for longevity and parts availability, this 320A represents a practical investment for operations requiring consistent uptime. The machine's traditional power system ensures straightforward maintenance and worldwide service support. Ready for immediate deployment in constructi

Caterpillar 320A

Proven performance meets industrial-grade engineering in this 2021 Sany SY415H excavator, currently located in Wenzhou, Zhejiang. With 41 tons of working weight and a powerful 257kW Isuzu 6UZ1 engine delivering maximum torque of 1363 N.m, this machine demonstrates why Sany has earned its reputation for building durable, reliable heavy equipment. Engineered for demanding jobsites, it offers a maximum digging depth of 7,045mm and impressive bucket digging force of 247kN, making quick work of tough excavation tasks.

<ul>
<li>Working Weight: 41,500 kg</li>
<li>Engine: Isuzu 6UZ1, 257kW @ 2000rpm, water-cooled</li>
<li>Bucket Capacity: 1.9/2.2 m³ (Rock)</li>
<li>Max Digging Reach: 10,920mm</li>
<li>Max Digging Depth: 7,045mm</li>
<li>Climbing Ability: 70% (35°)</li>
<li>Fuel Capacity: 690L for extended operation</li>
</ul>

Built to withstand years of intensive use, this workhorse combines robust construction with efficient hydraulics. Ready for immediate deployment on your next project.

Sany SY415H

Available now from our Wenzhou, Zhejiang facility, this 2016 Kobelco SK200 hydraulic excavator eliminates factory lead times and accelerates your project timeline. Powered by a reliable Mitsubishi 6D34-TLU2D engine delivering 110kW at 2000rpm with water-cooled, turbocharged technology, this 20-ton workhorse combines proven Japanese engineering with immediate deployment capability.

Equipped with a robust 0.8m³ backhoe bucket and dual variable displacement axial piston pumps, this machine generates 143kN bucket digging force (157kN supercharged) and 97.1kN arm force (107kN supercharged). Operating weight of 20,000kg ensures stability across diverse terrain, while dual travel speeds of 4.0/6.0 km/h and 70% climbing ability deliver exceptional mobility on demanding sites.

<ul>
<li>Engine: Mitsubishi 6D34-TLU2D, 110kW, turbocharged with intercooling</li>
<li>Hydraulics: 34.3MPa system pressure (37.8MPa supercharged)</li>
<li>Fuel capacity: 340L for extended operation</li>
<li>Track options: 600mm or 800mm width available</li>
<li>Location: Wenzhou, Zhejiang—ready for immediate inspection and shipment</li>
</ul>

Skip months of waiting. Secure this field-ready SK200 and mobilize your operations without delay.

Kobelco SK200

Commanding a 38-ton working weight with precision control, this 2021 XCMG XE380K excavator delivers professional-grade performance for demanding job sites. Operators benefit from enhanced cabin visibility and ergonomic controls that reduce fatigue during extended shifts. The 254kw rated power at 1900rpm drives a robust hydraulic system, generating 292kN bucket digging force for efficient material handling in challenging ground conditions.

<ul>
<li>38,500 kg working weight with superior stability</li>
<li>1.9-2.1 m³ backhoe bucket capacity for versatile applications</li>
<li>10,968 mm maximum digging radius extends operational reach</li>
<li>Fuel-efficient diesel power system</li>
<li>Manufactured in China with proven XCMG engineering</li>
<li>Currently located in Wenzhou, Zhejiang</li>
</ul>

Built for operators who prioritize control and productivity, this model features responsive hydraulics and balanced weight distribution that maintain stability across uneven terrain. The spacious cabin design provides clear sightlines to attachment points and work zones, enabling accurate positioning and reduced cycle times on excavation, loading, and trenching operations.

XCMG XE380K

Ready to deploy from 浙江温州, this 2019 Sany SY215C excavator delivers immediate productivity without factory wait times. Powered by a reliable Mitsubishi 4M50 engine producing 118 kW at 2000 rpm, this 21-ton workhorse combines proven performance with fast availability. Operating weight of 21,900 kg provides excellent stability, while the 1.1 m³ bucket (adjustable 0.8-1.2 m³) tackles diverse excavation tasks efficiently.

<ul>
<li>Immediate Availability: Located in 浙江温州 for rapid deployment to your project site</li>
<li>Performance Specs: 10,280 mm max digging reach, 6,600 mm digging depth, 138 kN bucket digging force</li>
<li>Reliable Power: Mitsubishi 4M50 water-cooled engine, 580 N·m torque, 390L fuel capacity</li>
<li>Operational Efficiency: 70% climbing ability, 5.4 km/h travel speed, 11 rpm rotation</li>
<li>Transport Dimensions: 9,680 mm (L) × 2,980 mm (W) × 3,440 mm (H)</li>
</ul>

Skip months of factory lead times. This Chinese-manufactured excavator is inspection-ready and available for immediate shipping. Contact Fair Trade Machinery today to secure fast delivery and put this machine to work on your site without delay.

Sany SY215C

Built in 2023, this Sany SY375H excavator delivers proven performance backed by one of China's most trusted heavy equipment manufacturers. Operating at 37 tons with a robust 212kW GH-6HK1XKSC engine, this machine combines a 1.9m³ bucket capacity with 235kN bucket digging force and 10,750mm maximum reach for demanding applications. Currently located in Wenzhou, Zhejiang Province, this unit represents exceptional value in the used market.

Why Sany Makes Financial Sense:
<ul>
<li>Parts Availability: Global dealer network ensures components ship quickly, minimizing downtime across Asia, Africa, and beyond</li>
<li>Resale Protection: Sany's market share growth means strong secondary demand when you're ready to upgrade</li>
<li>Service Infrastructure: Factory-trained technicians and comprehensive documentation reduce maintenance complexity</li>
<li>Proven Durability: Water-cooled turbocharged design with 540L fuel capacity ensures extended operation between services</li>
</ul>

With 70% climbing ability, 8.8 RPM rotation speed, and hydraulic systems engineered for Asian conditions, this SY375H offers reliability without the premium pricing

Sany SY375H

Designed for demanding jobsites, this 2022 Sany SY245H medium excavator delivers precision control and reliable performance in a 24-ton package. Powered by a robust D06FRC engine producing 147 kW at 2100 rpm with 750 N·m of torque, operators benefit from consistent hydraulic response across all working conditions. The spacious cabin provides commanding visibility over a maximum digging radius of 10,225 mm and excavation depth reaching 6,705 mm, enabling confident maneuvering in confined spaces.

<ul>
<li>Operator-Centric Design: Enhanced cabin ergonomics with clear sightlines to bucket and tracks, reducing fatigue during extended shifts</li>
<li>Stable Platform: 25,500 kg working weight with 53.2 kPa ground pressure ensures solid footing on varied terrain</li>
<li>Powerful Digging Force: 175 kN bucket force and 120 kN arm force tackle compacted materials efficiently</li>
<li>Smooth Controls: 10.6 rpm rotation speed and dual-speed travel (5.4/3.4 km/h) optimize cycle times</li>
<li>Service Access: Water-cooled 6-cylinder engine with accessible 475L fuel and 277L hydraulic tanks</li>
</ul>

Currently located in Wenzhou, Zhejiang, this Chinese-m

Sany SY245H

Engineered with Hitachi's renowned precision, this 2015 EX120-6 delivers consistent 12-ton performance across demanding jobsites. Powered by the robust Isuzu CC-4BG1TC engine generating 66kW of rated power, this joint venture-manufactured excavator combines Japanese reliability with field-proven hydraulic systems designed for extended duty cycles.

<ul>
<li>Year: 2015</li>
<li>Model: Hitachi EX120-6</li>
<li>Operating Weight: 12 tons</li>
<li>Engine: Isuzu CC-4BG1TC, 66kW rated output</li>
<li>Bucket Capacity: 0.52 m³ backhoe configuration</li>
<li>Power Type: Traditional diesel</li>
<li>Origin: Joint venture/Import manufacture</li>
<li>Current Location: Lishui, Zhejiang Province</li>
</ul>

Hydraulic response on the EX120-6 series remains among the smoothest in its class, offering operators precise control during grading, trenching, and loading operations. Traditional powertrain architecture ensures straightforward maintenance and parts availability worldwide. Currently positioned in Zhejiang Lishui, this machine represents proven mid-size excavator technology ready for immediate deployment.

Hitachi EX120-6

Engineered with precision for demanding excavation work, this 7-ton compact excavator delivers exceptional performance through advanced hydraulic systems and proven power technology. The v2607 engine generates 43kW at 2000rpm with maximum torque of 255.8N.m, providing reliable power across the 1400-1800rpm range. Hydraulic efficiency peaks at 160L/min main pump flow, translating to 57kN bucket digging force and 38kN rod digging force for superior material handling.

Technical specifications demonstrate robust engineering: 6260mm maximum digging radius, 4020mm digging depth, and 7085mm excavation height enable versatile jobsite applications. The 7450kg working weight maintains optimal 33.5kPa ground pressure, minimizing surface damage while maximizing stability. Compact transport dimensions of 6150mm length and 2230mm width facilitate efficient site-to-site mobility.

Operating features include dual travel speeds (5.4/2.9km/h), 10rpm rotation speed, and 68.32kN maximum tractive force. Fuel capacity of 130L and 115L hydraulic tank support extended work cycles. Currently available in Shaanxi, this Chinese-manufactured excavator represents proven XCMG quality for construction, utility, and landscaping operations.

XCMG XE75C

With a tonnage of 49, the 2021 Caterpillar 349E excavator, located in 福建福州, is a testament to robust engineering and reliability. Renowned for its traditional power and backhoe bucket, this machine is a preferred choice for demanding construction tasks. As a joint venture/import model, it benefits from Caterpillar's global support network, ensuring easy access to parts and maintenance services. This makes the 349E not only a durable addition to your fleet but also a smart investment with strong resale value. Trust in Caterpillar’s legacy for a machine that stands the test of time.

Caterpillar 349E

Built for precision and daily productivity, this 2016 Caterpillar E120B delivers reliable performance across demanding job sites. Operating at 12 tons with a 62.6 kW CATERPILLAR 3114 engine, this mid-size excavator combines proven hydraulic efficiency with operator-centered design. Currently located in Shenzhen, Guangdong, this machine offers excellent value for contractors seeking dependable excavation capability.

<ul>
<li>Operator Comfort: Spacious cab with 2700mm height provides clear sightlines to bucket and surrounding work zones, reducing fatigue during extended shifts</li>
<li>Stable Performance: 2780mm track ground length and 41.2 kPa ground pressure ensure balanced load distribution on varied terrain</li>
<li>Reach & Depth: Maximum digging depth of 5150mm and 7925mm excavation radius handle foundation work, trenching, and loading operations efficiently</li>
<li>Proven Powertrain: 4.4L displacement engine paired with 165L hydraulic system maintains consistent cycle times</li>
<li>Maneuverability: 2115mm rear turning radius and 2490mm transport width facilitate confined site navigation</li>
</ul>

Ideal for urban construction, utility

Caterpillar E120B

Proven in demanding conditions since 2017, this Sany SY245H crawler excavator demonstrates exceptional durability through years of reliable operation. Built with Sany's robust engineering standards in China, this 24-ton workhorse features a powerful D06FRC engine delivering 147kW at 2100rpm, paired with a water-cooled system designed for sustained heavy-duty performance. Operating weight of 25,500kg provides the stability needed for challenging excavation projects.

Performance credentials include impressive reach specifications: 10,225mm maximum digging radius and 6,705mm maximum digging depth. The 1.3-1.5m³ backhoe bucket generates 175kN of digging force, while the hydraulic system delivers consistent power through a 277L tank capacity. Track dimensions of 600mm width across 3,640mm ground contact length ensure superior traction and minimal ground pressure of just 53.2kPa.

Key specifications:
<ul>
<li>Rated Power: 147kW (2100rpm) with 750N.m maximum torque</li>
<li>Working Range: 10,225mm radius / 6,705mm depth / 9,745mm height</li>
<li>Fuel Capacity: 475L for extended operation</li>
<li>Transport Dimensions: 10,290mm × 3,190mm × 3,190mm</li>
<li>Current Location: Shanghai, Chin

Specifications	Value
No.	1045157
Tonnage (tons)	20
Working weight (kg)	21115
Bucket capacity (m³)	0.8
Boom length (mm)	5680
Rod length (mm)	2900
power	Traditional power
manufacturer	Joint venture/Import
bucket	backhoe
Engine type	Caterpillar CAT 3066 ATAAC
Rated power (kw/rpm)	110/1800
Cooling mode	water-cooling
Cylinder diameter × stroke (mm)	102 x 130
Displacement (L)	6.4
Ground specific pressure (Kpa)	48.02
Rotation speed (rpm)	11.5
Bucket digging force (kN)	132
Rod digging force (kN)	99
Travel speed (km/h)	5.5
Maximum flow of main pump (l/min)	205
Traveling Hydraulic Circuit (Mpa)	34.4
Rotary Hydraulic Circuit (Mpa)	26
Working Hydraulic Circuit (Mpa)	34.3
Pilot Oil Circuit (MPa)	4.12
Bucket cylinders - Number × diameter × stroke (mm)	1-120 x 1030
Bucket rod cylinders - Number × diameter × stroke (mm)	1-140 x 1430
Boom cylinders - Number × diameter × stroke (mm)	2-120 x 1260
Fuel Tank (L)	320
Hydraulic Tank (L)	120
Engine Oil changes (L)	30
Coolant (L)	24
Hydraulic System (L)	200
Total transport length (mm)	9390
Total transport width (mm)	2800
Total transport height (mm)	3050
Full cab height (mm)	3050
Minimum ground clearance (mm)	460
Back end turning radius (mm)	2770
Total track length (mm)	4070
Track gauge (mm)	2200
Track plate width (mm)	600
Total track width (mm)	2800
Track ground length (mm)	3260
Maximum digging depth (mm)	6550
Maximum excavation height (mm)	9440
Maximum unloading height (mm)	6770
Maximum vertical digging depth (mm)	5440
Maximum excavation radius of stop surface (mm)	9710

2009 Caterpillar 320C

Product Description

Overview

Brand Name：

Model Number：

Year：

Location：

Pub Date：
