2017 Caterpillar 320D2GC
Product Description
With a robust 20-ton working weight and a powerful Cat C7.1 engine, this 2017 Caterpillar 320D2GC excavator is designed for immediate deployment in demanding construction environments. Featuring a 0.9 m³ bucket capacity, it excels in digging, grading, and demolition tasks. Positioned in 湖南, this machine offers a rated power of 93 kW, ensuring efficient performance with a maximum digging force of 148 kN. Its 5.8 km/h travel speed and 206 kN maximum tractive force make it highly maneuverable on any site. Equipped with a 410 L fuel tank and a 138 L hydraulic tank, it provides extended operational hours without frequent refueling. The 320D2GC is a reliable, site-ready tool that delivers the power and precision needed to tackle a wide range of construction challenges.
| Specifications | Value |
|---|---|
| No. | 1033816 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 20100.0-20800.0 |
| Bucket capacity (m³) | 0.9 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cat C7.1 |
| Rated power (kw/rpm) | 93.0 |
| Cylinder diameter × stroke (mm) | 105 |
| Displacement (L) | 7.01 |
| Rotation speed (rpm) | 11.9 |
| Bucket digging force (kN) | 148 |
| Rod digging force (kN) | 108 |
| Maximum tractive force (kN) | 206 |
| Travel speed (km/h) | 5.8 |
| Maximum flow of main pump (l/min) | 428.0 |
| Rotary Hydraulic Circuit (Mpa) | 25.0 |
| Pilot pump flow (L/min) | 23.1 |
| Fuel Tank (L) | 410 |
| Hydraulic Tank (L) | 138.0 |
| Engine Oil changes (L) | 16 |
| Coolant (L) | 25 |
| Total transport length (mm) | 9460 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3030 |
| Full cab height (mm) | 2950 |
| Minimum ground clearance (mm) | 450 |
| Back end turning radius (mm) | 2750 |
| Total track length (mm) | 4080 |
| Track ground length (mm) | 3270 |
| Maximum digging depth (mm) | 6720 |
| Maximum excavation height (mm) | 6570 |
| Maximum unloading height (mm) | 6490 |
| Maximum vertical digging depth (mm) | 6010 |
Overview
No.1033816
Brand Name：
CaterpillarModel Number：
320D2GCYear：
2017
Location：
Hunan China
