2014 Caterpillar 323D2L

Engineered with Cat's proven C7.1 ACERT engine delivering 118 kW at 1,100 rpm, this 2014 323D2L excavator represents a benchmark in 23-ton class hydraulic performance. Dual main pumps supply 214 L/min each at 35 MPa working pressure, generating 140 kN bucket digging force and 107 kN arm digging force for demanding excavation tasks. With 7.01L displacement across six cylinders and optimized hydraulic flow management, this joint-venture manufactured unit maintains consistent power delivery across all functions.

Built on Caterpillar's D2L platform, this machine combines a 5,700 mm boom and 2,900 mm arm with a 1.19 m³ bucket capacity, achieving 6,720 mm maximum digging depth and 9,860 mm reach at ground level. The robust undercarriage features 600 mm track shoes across a 2,380 mm gauge, supporting 23,300 kg operating weight while maintaining 450 mm ground clearance. Dual-speed travel system provides 3.5 km/h precision and 5.6 km/h transport capability, backed by 205 kN maximum tractive effort for slope work up to 35°.

Currently located in Maoming, Guangdong, this Japanese-origin excavator offers proven reliability for infrastructure, mining, and heavy civil applications worldwide.
