2020 Caterpillar 324D

Built for operators who demand precision and control, the 2020 Caterpillar 324D is a 24-ton excavator engineered to perform on demanding job sites across any terrain. Sourced from Hebei, China, this machine carries a strong operational pedigree backed by a Japanese-origin build standard and Caterpillar's proven joint-venture manufacturing quality.

Powering every dig cycle is the C7 ACERT engine — a 7.2-liter, 6-cylinder water-cooled unit delivering 140 kW at 2,000 RPM. With a maximum digging depth of 6,740 mm and excavation radius reaching 10,030 mm, this machine handles a wide range of earthmoving and civil construction applications without compromise.

• Working Weight: 24,240 kg with 1 m³ backhoe bucket capacity
• Engine: CAT C7 ACERT | 140 kW / 2,000 RPM | 7.2L displacement
• Travel Speed: 3.5 / 5.5 km/h with 70% gradeability climbing ability
• Main Hydraulic Pressure: 35 MPa | Max pump flow: 235 L/min
• Boom / Arm Length: 5,900 mm / 2,950 mm
• Max Digging Depth: 6,740 mm | Max Excavation Height: 9,660 mm
• Fuel Tank: 520 L | Hydraulic System: 300 L
• Transport Dimensions: 10,060 mm (L) × 2,990 mm (W) × 3,170 mm (H)

Designed with operator comfort and site awareness in mind, the 324D's cab configuration provides strong sightlines across the work envelope, while the machine's stable 2,380 mm track gauge and 600 mm track plates deliver confident footing on uneven ground. For contractors seeking a reliable mid-size excavator with well-documented hydraulic performance and low operating complexity, this unit represents a direct, no-compromise solution.
