2016 Caterpillar 324DL
Product Description
Investing in proven machinery means choosing a brand that stands behind its equipment long after the sale. This 2016 Caterpillar 324DL hydraulic excavator, currently located in Guangxi, represents the kind of dependable performance that keeps operations running efficiently. Caterpillar's global parts network ensures components remain readily available, minimizing downtime and extending operational life well beyond initial deployment.
Consider the advantages of Caterpillar ownership in the used equipment market:
- Extensive dealer and parts support across China and internationally
- Strong resale value retention compared to competing brands
- Comprehensive service documentation and technical resources
- Proven hydraulic systems engineered for demanding applications
- Established reputation for durability in construction and excavation sectors
With seven years of field operation, this 324DL demonstrates the longevity Caterpillar equipment delivers. Parts availability remains robust, and technician familiarity with Cat systems translates to faster repairs and lower maintenance costs. For operators prioritizing long-term value and operational continuity, Caterpillar machiner
| Specifications | Value |
|---|---|
| No. | 994313 |
| Tonnage (tons) | 24 |
| Working weight (kg) | 25560 |
| Bucket capacity (m³) | 1.1 |
| Boom length (mm) | 5900 |
| Rod length (mm) | 2950 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | C7ACERT |
| Rated power (kw/rpm) | 140/2000 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 102 x 130 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.2 |
| Rotation speed (rpm) | 9.6 |
| Climbing ability (%) | 70/35 ° |
| Travel speed (km/h) | 3.5/5.5 |
| Main overflow set pressure (Mpa) | 35 |
| Maximum flow of main pump (l/min) | 235 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 24.5 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 35 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1-120 x 1104 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-140 x 1660 |
| Boom cylinders - Number × diameter × stroke (mm) | 2-135 x 1305 |
| Fuel Tank (L) | 520 |
| Hydraulic Tank (L) | 145 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 300(including fuel tank) |
| Total transport length (mm) | 10060 |
| Total transport width (mm) | 3390 |
| Total transport height (mm) | 3170 |
| Full cab height (mm) | 2980 |
| Counterweight ground clearance (mm) | 1060 |
| Minimum ground clearance (mm) | 470 |
| Back end turning radius (mm) | 2940 |
| Total track length (mm) | 4630 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 800 |
| Total track width (mm) | 3390 |
| Track ground length (mm) | 3830 |
| Maximum digging depth (mm) | 6740 |
| Maximum excavation height (mm) | 9660 |
| Maximum unloading height (mm) | 6700 |
| Maximum vertical digging depth (mm) | 5830 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 10030 |
| Maximum effective digging depth (mm) | 6560 |
Overview
No.994313
Brand Name：
CaterpillarModel Number：
324DLYear：
2016
Location：
Guangxi China
