2014 Caterpillar 326DL
Product Description
Expand your operational capacity with this 2014 Caterpillar 326DL hydraulic excavator, a proven 26-ton workhorse built for contractors managing multiple job sites. Powered by the robust Cat C7 ACERT engine delivering 140kW, this machine brings reliable performance to grading, trenching, and utility work without disrupting your primary fleet schedule.
- Working weight: 25,560 kg with excellent stability for slope work and heavy lifting
- Bucket capacity: 1.35-1.57 m³ handles diverse material types efficiently
- Maximum digging depth: 6,740 mm reaches deep utility lines and foundation prep
- Boom options: 5,300/5,900 mm with rod configurations from 2,000-2,950 mm adapt to varied applications
- Hydraulic power: 235 L/min main pump flow and 174 kN bucket force tackle demanding excavation
- Current location: Fujian, ready for inspection and deployment
Built at Caterpillar's Xuzhou facility with water-cooled reliability, this excavator integrates seamlessly alongside existing Cat equipment. Minimize downtime on concurrent projects while maintaining consistent productivity across your contractor operations.
| Specifications | Value |
|---|---|
| No. | 1026830 |
| Tonnage (tons) | 26 |
| Working weight (kg) | 25560 |
| Bucket capacity (m³) | 1.35/1.57 |
| Boom length (mm) | 5300/5900 |
| Rod length (mm) | 2000/2500/2950 |
| Country of origin | Xuzhou, Jiangsu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar C7 ACERT |
| Rated power (kw/rpm) | 140 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 110 x 127 |
| Displacement (L) | 7.2 |
| Rotation speed (rpm) | 9.6 |
| Bucket digging force (kN) | 174 |
| Rod digging force (kN) | 122 |
| Maximum tractive force (kN) | 227 |
| Travel speed (km/h) | 5.5 |
| Turning torque (Nm) | 73.4 |
| Main overflow set pressure (Mpa) | 35 |
| Rotary hydraulic motor type | 24.5 |
| Type of walking hydraulic motor | 35 |
| Maximum flow of main pump (l/min) | 235 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 150 x 1156 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 140 x 1660 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 135 x 1305 |
| Fuel Tank (L) | 520 |
| Hydraulic Tank (L) | 145 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 300 |
| Total transport length (mm) | 10060 |
| Total transport width (mm) | 3390 |
| Total transport height (mm) | 3170 |
| Full cab height (mm) | 2980 |
| Counterweight ground clearance (mm) | 1060 |
| Minimum ground clearance (mm) | 470 |
| Back end turning radius (mm) | 2940 |
| Total track length (mm) | 4630 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3390 |
| Maximum digging depth (mm) | 6740 |
| Maximum excavation height (mm) | 9660 |
| Maximum unloading height (mm) | 6700 |
| Maximum vertical digging depth (mm) | 5830 |
| Maximum excavation radius of stop surface (mm) | 10030 |
| Maximum effective digging depth (mm) | 6560 |
