2017 Caterpillar 326DL
Product Description
Engineered with Caterpillar's proven C7 ACERT engine delivering 140 kW of rated power, this 2017 326DL excavator represents precision-built performance for demanding applications. The 26-ton machine combines a robust 7.2L displacement engine with an advanced hydraulic system featuring 235 l/min maximum pump flow and 35 MPa main overflow pressure, ensuring consistent power delivery across all operating conditions.
Technical specifications demonstrate superior capability:
- Working weight of 25,560 kg with optimal balance for stability
- Bucket digging force reaches 174 kN, rod digging force 122 kN
- Maximum digging depth of 6,740 mm with 10,030 mm excavation radius
- Dual boom options (5,300/5,900 mm) and multiple rod configurations for versatility
- Water-cooled system with 520L fuel capacity for extended operation
Currently located in Wenzhou, Zhejiang, this joint venture-manufactured unit exemplifies Caterpillar's commitment to engineering excellence. The 600 mm track plates and 2,590 mm gauge provide exceptional ground contact, while the 9.6 rpm rotation speed ensures efficient cycle times in high-production environments.
| Specifications | Value |
|---|---|
| No. | 997057 |
| Tonnage (tons) | 26 |
| Working weight (kg) | 25560 |
| Bucket capacity (m³) | 1.35/1.57 |
| Boom length (mm) | 5300/5900 |
| Rod length (mm) | 2000/2500/2950 |
| Country of origin | Xuzhou, Jiangsu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar C7 ACERT |
| Rated power (kw/rpm) | 140 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 110 x 127 |
| Displacement (L) | 7.2 |
| Rotation speed (rpm) | 9.6 |
| Bucket digging force (kN) | 174 |
| Rod digging force (kN) | 122 |
| Maximum tractive force (kN) | 227 |
| Travel speed (km/h) | 5.5 |
| Turning torque (Nm) | 73.4 |
| Main overflow set pressure (Mpa) | 35 |
| Rotary hydraulic motor type | 24.5 |
| Type of walking hydraulic motor | 35 |
| Maximum flow of main pump (l/min) | 235 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 150 x 1156 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 140 x 1660 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 135 x 1305 |
| Fuel Tank (L) | 520 |
| Hydraulic Tank (L) | 145 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 300 |
| Total transport length (mm) | 10060 |
| Total transport width (mm) | 3390 |
| Total transport height (mm) | 3170 |
| Full cab height (mm) | 2980 |
| Counterweight ground clearance (mm) | 1060 |
| Minimum ground clearance (mm) | 470 |
| Back end turning radius (mm) | 2940 |
| Total track length (mm) | 4630 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3390 |
| Maximum digging depth (mm) | 6740 |
| Maximum excavation height (mm) | 9660 |
| Maximum unloading height (mm) | 6700 |
| Maximum vertical digging depth (mm) | 5830 |
| Maximum excavation radius of stop surface (mm) | 10030 |
| Maximum effective digging depth (mm) | 6560 |
