2021 Caterpillar 326DL
Product Description
Acquire proven excavation power without the premium price tag. This 2021 Caterpillar 326DL delivers 26-ton performance with the reliability of Cat's C7 ACERT engine, producing 140kW of rated power backed by advanced hydraulic systems. With only minimal operational hours since manufacture, this machine offers near-new capability at a fraction of replacement cost—making it a strategic choice for contractors seeking maximum ROI.
- Engine: Caterpillar C7 ACERT, 140kW, water-cooled, 7.2L displacement
- Capacity: 1.35/1.57 m³ bucket, 174kN bucket digging force
- Reach: 10,030mm maximum excavation radius, 6,740mm digging depth
- Hydraulics: 235 L/min main pump flow, 35MPa system pressure
- Versatility: Multiple boom (5,300/5,900mm) and arm (2,000/2,500/2,950mm) configurations
- Mobility: 25,560kg working weight, 5.5 km/h travel speed
- Location: Jinan, Shandong—ready for immediate deployment
Invest intelligently in equipment that maintains Caterpillar's engineering standards while preserving capital for operational growth. Specifications confirm full oper
| Specifications | Value |
|---|---|
| No. | 1010836 |
| Tonnage (tons) | 26 |
| Working weight (kg) | 25560 |
| Bucket capacity (m³) | 1.35/1.57 |
| Boom length (mm) | 5300/5900 |
| Rod length (mm) | 2000/2500/2950 |
| Country of origin | Xuzhou, Jiangsu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar C7 ACERT |
| Rated power (kw/rpm) | 140 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 110 x 127 |
| Displacement (L) | 7.2 |
| Rotation speed (rpm) | 9.6 |
| Bucket digging force (kN) | 174 |
| Rod digging force (kN) | 122 |
| Maximum tractive force (kN) | 227 |
| Travel speed (km/h) | 5.5 |
| Turning torque (Nm) | 73.4 |
| Main overflow set pressure (Mpa) | 35 |
| Rotary hydraulic motor type | 24.5 |
| Type of walking hydraulic motor | 35 |
| Maximum flow of main pump (l/min) | 235 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 150 x 1156 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 140 x 1660 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 135 x 1305 |
| Fuel Tank (L) | 520 |
| Hydraulic Tank (L) | 145 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 300 |
| Total transport length (mm) | 10060 |
| Total transport width (mm) | 3390 |
| Total transport height (mm) | 3170 |
| Full cab height (mm) | 2980 |
| Counterweight ground clearance (mm) | 1060 |
| Minimum ground clearance (mm) | 470 |
| Back end turning radius (mm) | 2940 |
| Total track length (mm) | 4630 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3390 |
| Maximum digging depth (mm) | 6740 |
| Maximum excavation height (mm) | 9660 |
| Maximum unloading height (mm) | 6700 |
| Maximum vertical digging depth (mm) | 5830 |
| Maximum excavation radius of stop surface (mm) | 10030 |
| Maximum effective digging depth (mm) | 6560 |
see more
Overview
No.1010836
Brand Name：
CaterpillarModel Number：
326DLYear：
2021
Location：
Shandong China
Pub Date：
