2022 Caterpillar 326DL
Product Description
Positioned in Hubei and ready for immediate deployment, this 2022 Caterpillar 326DL excavator eliminates factory wait times and accelerates your project timeline. Operating at 26 tons with a robust 140kW Caterpillar C7 ACERT engine, this machine delivers reliable performance for demanding excavation work. Equipped with a 1.35/1.57 m³ bucket capacity and impressive digging forces—174 kN bucket force and 122 kN rod force—it handles heavy-duty applications with precision.
Key specifications include:
- Maximum digging depth: 6,740 mm with 10,030 mm excavation radius
- Hydraulic system: 235 L/min main pump flow at 35 MPa
- Travel speed: 5.5 km/h for efficient site mobility
- Fuel capacity: 520L for extended operation cycles
- Transport dimensions: 10,060 × 3,390 × 3,170 mm
Available now from our Hubei location, this joint-venture manufactured excavator offers fast deployment to your construction site. Skip extended lead times and maintain project momentum with immediate access to proven Caterpillar engineering and water-cooled reliability. Contact us today to arrange swift delivery and get your operations moving.
| Specifications | Value |
|---|---|
| No. | 993676 |
| Tonnage (tons) | 26 |
| Working weight (kg) | 25560 |
| Bucket capacity (m³) | 1.35/1.57 |
| Boom length (mm) | 5300/5900 |
| Rod length (mm) | 2000/2500/2950 |
| Country of origin | Xuzhou, Jiangsu |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar C7 ACERT |
| Rated power (kw/rpm) | 140 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 110 x 127 |
| Displacement (L) | 7.2 |
| Rotation speed (rpm) | 9.6 |
| Bucket digging force (kN) | 174 |
| Rod digging force (kN) | 122 |
| Maximum tractive force (kN) | 227 |
| Travel speed (km/h) | 5.5 |
| Turning torque (Nm) | 73.4 |
| Main overflow set pressure (Mpa) | 35 |
| Rotary hydraulic motor type | 24.5 |
| Type of walking hydraulic motor | 35 |
| Maximum flow of main pump (l/min) | 235 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 150 x 1156 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 140 x 1660 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 135 x 1305 |
| Fuel Tank (L) | 520 |
| Hydraulic Tank (L) | 145 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 300 |
| Total transport length (mm) | 10060 |
| Total transport width (mm) | 3390 |
| Total transport height (mm) | 3170 |
| Full cab height (mm) | 2980 |
| Counterweight ground clearance (mm) | 1060 |
| Minimum ground clearance (mm) | 470 |
| Back end turning radius (mm) | 2940 |
| Total track length (mm) | 4630 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3390 |
| Maximum digging depth (mm) | 6740 |
| Maximum excavation height (mm) | 9660 |
| Maximum unloading height (mm) | 6700 |
| Maximum vertical digging depth (mm) | 5830 |
| Maximum excavation radius of stop surface (mm) | 10030 |
| Maximum effective digging depth (mm) | 6560 |
