2011 Caterpillar 329D
Product Description
Built for serious excavation work, this 2011 Caterpillar 329D delivers 152kW of proven C7 ACERT power to handle demanding jobsite tasks. With a 29-ton operating weight and 1.1m³ bucket capacity, this machine tackles deep foundation work, site preparation, and heavy material handling with consistent reliability. Maximum digging depth reaches 7,170mm while the 10,600mm excavation radius provides extensive working range without repositioning.
Engineered for productivity, the hydraulic system pumps 235 liters per minute at 35MPa, ensuring responsive control during grading, trenching, and loading operations. The 6,150mm boom and 3,200mm arm configuration optimize reach and breakout force for demolition and bulk earthmoving. Water-cooled 7.2L six-cylinder engine maintains performance in extended duty cycles.
- 29-ton working weight for stability on uneven terrain
- 10.2 rpm rotation speed enables efficient truck loading
- 520L fuel tank supports full-shift operation
- Currently located in Fujian, available for immediate deployment
- Japanese-origin joint venture manufacturing ensures quality standards
Ready to move earth, dig foundations, or clear sites—this 329D is prepared f
| Specifications | Value |
|---|---|
| No. | 1019527 |
| Tonnage (tons) | 29 |
| Working weight (kg) | 29240 |
| Bucket capacity (m³) | 1.1 |
| Boom length (mm) | 6150 |
| Rod length (mm) | 3200 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | C7ACERT |
| Rated power (kw/rpm) | 152/2000 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 110 x 127 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.2 |
| Rotation speed (rpm) | 10.2 |
| Climbing ability (%) | 70/35 ° |
| Travel speed (km/h) | 3.5/5.3 |
| Main overflow set pressure (Mpa) | 3.5 |
| Maximum flow of main pump (l/min) | 235 |
| Traveling Hydraulic Circuit (Mpa) | 3.5 |
| Rotary Hydraulic Circuit (Mpa) | 2.75 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 3.5 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 135 x 1156 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 150 x 1646 |
| Boom cylinders - Number × diameter × stroke (mm) | 140 x 1407 |
| Fuel Tank (L) | 520 |
| Hydraulic Tank (L) | 145 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 310(including fuel tank) |
| Total transport length (mm) | 10410 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3180 |
| Full cab height (mm) | 3040 |
| Counterweight ground clearance (mm) | 1110 |
| Minimum ground clearance (mm) | 490 |
| Back end turning radius (mm) | 3080 |
| Total track length (mm) | 4360 |
| Track gauge (mm) | 2390 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2990 |
| Track ground length (mm) | 3490 |
| Maximum digging depth (mm) | 7170 |
| Maximum excavation height (mm) | 9990 |
| Maximum unloading height (mm) | 7020 |
| Maximum vertical digging depth (mm) | 6510 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 10600 |
| Maximum effective digging depth (mm) | 7010 |
Overview
