2016 Caterpillar 329D
Product Description
Available now in Fujian Quanzhou, this 2016 Caterpillar 329D hydraulic excavator delivers immediate deployment without factory wait times. Powered by a C7ACERT engine producing 152kW at 2000rpm, this 29-ton workhorse combines Japanese engineering precision with proven reliability for demanding jobsite conditions. Water-cooled 7.2L displacement ensures consistent performance across extended operating cycles.
Engineered for maximum productivity, the machine features a 6150mm boom and 3200mm arm, achieving 10600mm maximum digging reach and 7170mm digging depth. Hydraulic systems operate at 3.5MPa working pressure with 235L/min main pump flow, supported by a 520L fuel tank and 310L total hydraulic capacity. The 1.1m³ bucket capacity handles substantial material volumes efficiently.
Skip months-long factory lead times. This unit is inspection-ready in Quanzhou with fast logistics to your project site across Asia-Pacific, Middle East, or African markets. Compact transport dimensions (10410mm length × 2990mm width) facilitate container shipping and regional road transport.
- 29-ton operating weight, 152kW rated power
- 10600mm max reach, 7170mm dig depth
- C7ACERT engine with water-cooling system
| Specifications | Value |
|---|---|
| No. | 1050530 |
| Tonnage (tons) | 29 |
| Working weight (kg) | 29240 |
| Bucket capacity (m³) | 1.1 |
| Boom length (mm) | 6150 |
| Rod length (mm) | 3200 |
| Country of origin | Japan |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | C7ACERT |
| Rated power (kw/rpm) | 152/2000 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 110 x 127 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 7.2 |
| Rotation speed (rpm) | 10.2 |
| Climbing ability (%) | 70/35 ° |
| Travel speed (km/h) | 3.5/5.3 |
| Main overflow set pressure (Mpa) | 3.5 |
| Maximum flow of main pump (l/min) | 235 |
| Traveling Hydraulic Circuit (Mpa) | 3.5 |
| Rotary Hydraulic Circuit (Mpa) | 2.75 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 3.5 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 135 x 1156 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 150 x 1646 |
| Boom cylinders - Number × diameter × stroke (mm) | 140 x 1407 |
| Fuel Tank (L) | 520 |
| Hydraulic Tank (L) | 145 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 310(including fuel tank) |
| Total transport length (mm) | 10410 |
| Total transport width (mm) | 2990 |
| Total transport height (mm) | 3180 |
| Full cab height (mm) | 3040 |
| Counterweight ground clearance (mm) | 1110 |
| Minimum ground clearance (mm) | 490 |
| Back end turning radius (mm) | 3080 |
| Total track length (mm) | 4360 |
| Track gauge (mm) | 2390 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 2990 |
| Track ground length (mm) | 3490 |
| Maximum digging depth (mm) | 7170 |
| Maximum excavation height (mm) | 9990 |
| Maximum unloading height (mm) | 7020 |
| Maximum vertical digging depth (mm) | 6510 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 10600 |
| Maximum effective digging depth (mm) | 7010 |
