2016 Caterpillar 330B
Product Description
Maximize productivity without the premium price tag. This 2016 Caterpillar 330B excavator delivers 30-ton performance with proven reliability, representing exceptional value compared to new equipment investments. Powered by a robust Caterpillar 3306TA turbocharged engine producing 165.5kW at 1800rpm, this machine handles demanding excavation tasks with 1.5m³ bucket capacity and impressive reach specifications: 11,620mm maximum excavation radius and 8,080mm digging depth.
Built for serious earthmoving operations, the 330B combines a high-capacity 480 l/min hydraulic system with water-cooled efficiency across its 6-cylinder, 10.5L displacement engine. Currently located in Xuzhou, Jiangsu, this joint venture/import model maintains Caterpillar's legendary durability while offering significant cost savings.
- Working weight: 32,420kg with optimal stability
- Extended reach: 6,500mm boom, 3,900mm arm configuration
- 34.3Mpa main overflow pressure for consistent power delivery
- 560L fuel capacity supports extended operation cycles
- Transport dimensions: 11,080mm (L) × 3,340mm (W) × 3,610mm (H)
Invest smart. Pay less. Perform more.
| Specifications | Value |
|---|---|
| No. | 1018731 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 32420 |
| Bucket capacity (m³) | 1.5 |
| Boom length (mm) | 6500 |
| Rod length (mm) | 3900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar 3306TA |
| Rated power (kw/rpm) | 165.5/1800 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 10.5 |
| Working form | Turbocharging; after-cooling |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 480 |
| Fuel Tank (L) | 560 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 45 |
| Hydraulic System (L) | 400 |
| Total transport length (mm) | 11080 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3610 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1260 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3500 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 4040 |
| Maximum digging depth (mm) | 8080 |
| Maximum excavation height (mm) | 10770 (Cutting) |
| Maximum unloading height (mm) | 7600 |
| Maximum vertical digging depth (mm) | 7230 |
| Maximum excavation radius of stop surface (mm) | 11620 |
| Travel speed (km/h) | 4.6 |
Overview
No.1018731
Brand Name：
CaterpillarModel Number：
330BYear：
2016
Location：
Jiangsu China
Pub Date：
