2016 Caterpillar 330B
Product Description
Built for demanding jobsites, the Caterpillar 330B delivers 30-ton class performance with a working weight of 32,420 kg and a 1.5 m³ backhoe bucket engineered for high-volume digging cycles. Powered by the proven Caterpillar 3306TA six-cylinder turbocharged and after-cooled engine producing 165.5 kW at 1,800 RPM, this machine maintains consistent hydraulic output — with a maximum main pump flow of 480 L/min and a system pressure of 34.3 MPa — across extended shifts in heavy material conditions.
From the operator's seat, control is immediate and fatigue is managed. The cab design of this era prioritizes forward visibility and ergonomic control placement, keeping the operator oriented through a maximum digging depth of 8,080 mm and a digging radius of 11,620 mm. Stability is reinforced by a 2,590 mm track gauge with 600 mm track plates, providing a firm platform on uneven terrain.
- Engine: Caterpillar 3306TA | 6-cylinder | 10.5 L displacement | Water-cooled
- Rated Power: 165.5 kW / 1,800 RPM
- Maximum Digging Depth: 8,080 mm
- Maximum Excavation Radius: 11,620 mm
- Maximum Unloading Height: 7,600 mm
- Boom Length: 6,500 mm | Rod Length: 3,900 mm
- Fuel Tank:
| Specifications | Value |
|---|---|
| No. | 1026550 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 32420 |
| Bucket capacity (m³) | 1.5 |
| Boom length (mm) | 6500 |
| Rod length (mm) | 3900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar 3306TA |
| Rated power (kw/rpm) | 165.5/1800 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 10.5 |
| Working form | Turbocharging; after-cooling |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 480 |
| Fuel Tank (L) | 560 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 45 |
| Hydraulic System (L) | 400 |
| Total transport length (mm) | 11080 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3610 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1260 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3500 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 4040 |
| Maximum digging depth (mm) | 8080 |
| Maximum excavation height (mm) | 10770 (Cutting) |
| Maximum unloading height (mm) | 7600 |
| Maximum vertical digging depth (mm) | 7230 |
| Maximum excavation radius of stop surface (mm) | 11620 |
| Travel speed (km/h) | 4.6 |
Overview
No.1026550
Brand Name：
CaterpillarModel Number：
330BYear：
2016
Location：
Sichuan China
Pub Date：
