2016 Caterpillar 330B
Product Description
With a working weight of 32,420 kg and a bucket capacity of 1.5 m³, this 2016 Caterpillar 330B excavator stands as a testament to durability and reliability. Located in 湖南, it features a powerful Caterpillar 3306TA engine, delivering 165.5 kW at 1800 rpm, ensuring robust performance on any job site. The machine's design includes a 6-cylinder, water-cooled, turbocharged, and after-cooled engine, which enhances its operational efficiency and longevity.
- Boom length: 6,500 mm; Rod length: 3,900 mm
- Total transport dimensions: 11,080 mm (length) x 3,340 mm (width) x 3,610 mm (height)
- Maximum digging depth: 8,080 mm; Maximum excavation height: 10,770 mm (Cutting)
- Fuel tank capacity: 560 L; Hydraulic system capacity: 400 L
- Track gauge: 2,590 mm; Track plate width: 600 mm
Built to last, this excavator has proven itself as a reliable workhorse, capable of handling the toughest jobs with ease. Its robust construction and high-performance specifications make it an ideal choice for demanding construction and excavation projects.
| Specifications | Value |
|---|---|
| No. | 1032388 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 32420 |
| Bucket capacity (m³) | 1.5 |
| Boom length (mm) | 6500 |
| Rod length (mm) | 3900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar 3306TA |
| Rated power (kw/rpm) | 165.5/1800 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 10.5 |
| Working form | Turbocharging; after-cooling |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 480 |
| Fuel Tank (L) | 560 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 45 |
| Hydraulic System (L) | 400 |
| Total transport length (mm) | 11080 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3610 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1260 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3500 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 4040 |
| Maximum digging depth (mm) | 8080 |
| Maximum excavation height (mm) | 10770 (Cutting) |
| Maximum unloading height (mm) | 7600 |
| Maximum vertical digging depth (mm) | 7230 |
| Maximum excavation radius of stop surface (mm) | 11620 |
| Travel speed (km/h) | 4.6 |
Overview
No.1032388
Brand Name：
CaterpillarModel Number：
330BYear：
2016
Location：
Hunan China
