2018 Caterpillar 330B
Product Description
Expand your operational capacity with this robust 2018 Caterpillar 330B excavator, currently located in Shaoxing, Zhejiang. Built for contractors running multiple jobsites simultaneously, this 30-ton workhorse delivers proven reliability when your primary fleet is stretched thin. Powered by the legendary Caterpillar 3306TA turbocharged and aftercooled engine producing 165.5kW at 1800rpm, it handles demanding excavation tasks with consistent hydraulic performance—34.3 MPa system pressure and 480 L/min main pump flow ensure responsive cycle times under load.
- Operating Capacity: 32,420 kg working weight | 1.5 m³ bucket capacity
- Reach & Depth: 11,620 mm maximum excavation radius | 8,080 mm maximum dig depth
- Boom/Arm Configuration: 6,500 mm boom | 3,900 mm stick for versatile applications
- Mobility: 4,040 mm track ground length | 600 mm track plates for stable positioning
- Fuel Autonomy: 560-liter tank supports extended shifts without refueling interruptions
Joint venture/import build quality ensures parts compatibility across Caterpillar service networks. Ready to integrate seamlessly into e
| Specifications | Value |
|---|---|
| No. | 1030227 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 32420 |
| Bucket capacity (m³) | 1.5 |
| Boom length (mm) | 6500 |
| Rod length (mm) | 3900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar 3306TA |
| Rated power (kw/rpm) | 165.5/1800 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 10.5 |
| Working form | Turbocharging; after-cooling |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 480 |
| Fuel Tank (L) | 560 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 45 |
| Hydraulic System (L) | 400 |
| Total transport length (mm) | 11080 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3610 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1260 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3500 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 4040 |
| Maximum digging depth (mm) | 8080 |
| Maximum excavation height (mm) | 10770 (Cutting) |
| Maximum unloading height (mm) | 7600 |
| Maximum vertical digging depth (mm) | 7230 |
| Maximum excavation radius of stop surface (mm) | 11620 |
| Travel speed (km/h) | 4.6 |
Overview
No.1030227
Brand Name：
CaterpillarModel Number：
330BYear：
2018
Location：
Zhejiang China
