2019 Caterpillar 330B
Product Description
Powered by the robust Caterpillar 3306TA engine, this 2019 Caterpillar 330B excavator delivers a rated power of 165.5 kW at 1800 rpm, ensuring reliable performance in demanding environments. Equipped with a 480 l/min main pump and a main overflow set pressure of 34.3 Mpa, the hydraulic system provides precise control and high efficiency.
- Working weight: 32,420 kg
- Bucket capacity: 1.5 m³
- Boom length: 6,500 mm
- Rod length: 3,900 mm
- Engine type: Water-cooled, 6-cylinder, 10.5 L displacement
- Maximum digging depth: 8,080 mm
- Maximum excavation height: 10,770 mm (Cutting)
- Travel speed: 4.6 km/h
Manufactured as a joint venture/import, this model is engineered for durability and productivity. The full cab height of 3,150 mm and a counterweight ground clearance of 1,260 mm enhance operator comfort and safety. With a fuel tank capacity of 560 L and a total transport length of 11,080 mm, it is designed for long hours of operation and easy transportation.
| Specifications | Value |
|---|---|
| No. | 1020681 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 32420 |
| Bucket capacity (m³) | 1.5 |
| Boom length (mm) | 6500 |
| Rod length (mm) | 3900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar 3306TA |
| Rated power (kw/rpm) | 165.5/1800 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 10.5 |
| Working form | Turbocharging; after-cooling |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 480 |
| Fuel Tank (L) | 560 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 45 |
| Hydraulic System (L) | 400 |
| Total transport length (mm) | 11080 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3610 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1260 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3500 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 4040 |
| Maximum digging depth (mm) | 8080 |
| Maximum excavation height (mm) | 10770 (Cutting) |
| Maximum unloading height (mm) | 7600 |
| Maximum vertical digging depth (mm) | 7230 |
| Maximum excavation radius of stop surface (mm) | 11620 |
| Travel speed (km/h) | 4.6 |
Overview
No.1020681
Brand Name：
CaterpillarModel Number：
330BYear：
2019
Location：
Jiangsu China
