2019 Caterpillar 330B
Product Description
Engineered for demanding excavation operations, this 2019 Caterpillar 330B delivers exceptional performance through proven hydraulic and powertrain systems. The machine's Caterpillar 3306TA engine generates 165.5 kW at 1800 rpm, featuring turbocharged after-cooled technology with 10.5L displacement across six cylinders. Water-cooled efficiency ensures sustained operation under heavy loads.
Hydraulic capacity defines operational capability: the main pump flows 480 l/min at 34.3 Mpa pressure, powering a 1.5 m³ backhoe bucket through extensive reach parameters. Maximum excavation depth extends to 8,080 mm while maintaining an 11,620 mm stop-surface radius. The 6,500 mm boom and 3,900 mm arm configuration optimize material handling across varied applications.
- Operating weight: 32,420 kg with robust 30-ton capacity
- Track dimensions: 4,040 mm ground length, 600 mm plate width
- Fluid capacities: 560L fuel, 400L hydraulic system
- Transport dimensions: 11,080 × 3,340 × 3,610 mm
- Location: Hunan Province, ready for inspection
Joint venture manufacturing standards ensure component reliability and serviceability throughout this excavator's operational lifecycle.
| Specifications | Value |
|---|---|
| No. | 1025243 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 32420 |
| Bucket capacity (m³) | 1.5 |
| Boom length (mm) | 6500 |
| Rod length (mm) | 3900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar 3306TA |
| Rated power (kw/rpm) | 165.5/1800 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 10.5 |
| Working form | Turbocharging; after-cooling |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 480 |
| Fuel Tank (L) | 560 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 45 |
| Hydraulic System (L) | 400 |
| Total transport length (mm) | 11080 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3610 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1260 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3500 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 4040 |
| Maximum digging depth (mm) | 8080 |
| Maximum excavation height (mm) | 10770 (Cutting) |
| Maximum unloading height (mm) | 7600 |
| Maximum vertical digging depth (mm) | 7230 |
| Maximum excavation radius of stop surface (mm) | 11620 |
| Travel speed (km/h) | 4.6 |
