2019 Caterpillar 330B






Product Description
This 2019 Caterpillar 330B excavator offers reliable performance for heavy-duty construction and earthmoving applications. With approximately 7,000 actual operating hours recorded, this machine demonstrates low utilization for its age, indicating careful operation and maintenance. Currently located in Guangxi, China, this unit is available for immediate inspection and acquisition.
Key highlights:
- Low hours relative to model year
- Caterpillar's proven hydraulic system and undercarriage design
- Suitable for excavation, trenching, and material handling
- Ready for deployment in mining, infrastructure, or civil engineering projects
This excavator represents a cost-effective solution for contractors seeking dependable mid-sized equipment with substantial remaining service life. Contact us for detailed specifications, pricing, and shipping arrangements.
| Specifications | Value |
|---|---|
| No. | 1106173 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 32420 |
| Bucket capacity (m³) | 1.5 |
| Boom length (mm) | 6500 |
| Rod length (mm) | 3900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar 3306TA |
| Rated power (kw/rpm) | 165.5/1800 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 10.5 |
| Working form | Turbocharging; after-cooling |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 480 |
| Fuel Tank (L) | 560 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 45 |
| Hydraulic System (L) | 400 |
| Total transport length (mm) | 11080 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3610 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1260 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3500 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 4040 |
| Maximum digging depth (mm) | 8080 |
| Maximum excavation height (mm) | 10770 (Cutting) |
| Maximum unloading height (mm) | 7600 |
| Maximum vertical digging depth (mm) | 7230 |
| Maximum excavation radius of stop surface (mm) | 11620 |
| Travel speed (km/h) | 4.6 |
Overview
No.1106173
Brand Name:
CaterpillarModel Number:
330BYear:
2019
Location:
Guangxi China
Pub Date:
