2020 Caterpillar 330B
Product Description
Built for precision and performance, this 2020 Caterpillar 330B excavator delivers 30 tons of reliable power on demanding jobsites. Operators benefit from superior cabin visibility and ergonomic controls, ensuring accurate bucket placement across an impressive 11,620mm maximum excavation radius. The spacious cab sits at 3,150mm height, providing commanding sightlines to the work area while maintaining excellent stability through a 3,500mm rear turning radius.
- Caterpillar 3306TA engine: 165.5kW at 1800rpm with turbocharged, after-cooled efficiency
- Responsive hydraulics: 480 L/min main pump flow at 34.3 Mpa for smooth, controlled operation
- Maximum digging depth of 8,080mm with 1.5m³ bucket capacity
- Stable 32,420kg working weight with 600mm track plates for confident grading
- Water-cooled 6-cylinder, 10.5L displacement engine for extended runtime
- Located in Huizhou, Guangdong—ready for immediate deployment
Engineered for operators who demand comfort during long shifts, this joint venture/import machine combines proven Caterpillar durability with intuitive handling characteristics that reduce fatigue and maximize productivity.
| Specifications | Value |
|---|---|
| No. | 1030870 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 32420 |
| Bucket capacity (m³) | 1.5 |
| Boom length (mm) | 6500 |
| Rod length (mm) | 3900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar 3306TA |
| Rated power (kw/rpm) | 165.5/1800 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 10.5 |
| Working form | Turbocharging; after-cooling |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 480 |
| Fuel Tank (L) | 560 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 45 |
| Hydraulic System (L) | 400 |
| Total transport length (mm) | 11080 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3610 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1260 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3500 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 4040 |
| Maximum digging depth (mm) | 8080 |
| Maximum excavation height (mm) | 10770 (Cutting) |
| Maximum unloading height (mm) | 7600 |
| Maximum vertical digging depth (mm) | 7230 |
| Maximum excavation radius of stop surface (mm) | 11620 |
| Travel speed (km/h) | 4.6 |
Overview
No.1030870
Brand Name：
CaterpillarModel Number：
330BYear：
2020
Location：
Guangdong China
Pub Date：
