2020 Caterpillar 330B

Built for demanding excavation work, the 2020 Caterpillar 330B delivers proven performance across large-scale earthmoving, trenching, and material handling operations. Powered by the robust Caterpillar 3306TA 6-cylinder, 10.5L turbocharged and after-cooled engine producing 165.5 kW at 1,800 RPM, this 30-ton machine offers the muscle and precision operators depend on in high-output environments. Currently located in Hunan, China, and available for global export.

From the operator's seat, the 330B provides a commanding view of the work area, with a spacious cab designed to reduce fatigue during extended shifts. Controls respond with confidence, supported by a high-flow hydraulic system running at up to 480 L/min and a main relief pressure of 34.3 MPa — ensuring smooth, consistent bucket and boom response throughout the working cycle.

• Engine: Caterpillar 3306TA | 6-Cylinder | 10.5L | 165.5 kW @ 1,800 RPM | Water-Cooled
• Operating Weight: 32,420 kg | Bucket Capacity: 1.5 m³
• Max Digging Depth: 8,080 mm | Max Reach at Ground Level: 11,620 mm
• Max Excavation Height: 10,770 mm | Max Dump Height: 7,600 mm
• Boom / Stick: 6,500 mm / 3,900 mm
• Hydraulic Tank: 400 L | Fuel Tank: 560 L
• Track Width: 600 mm | Travel Speed: 4.6 km/h
• Transport Dimensions: 11,080 mm (L) × 3,340 mm (W) × 3,610 mm (H)
