2022 Caterpillar 330B
Product Description
Ready to deploy from our Jiangsu facility, this 2022 Caterpillar 330B excavator delivers 30-ton performance without factory wait times. Powered by a Caterpillar 3306TA engine producing 165.5 kW at 1800 rpm, this machine combines turbocharged, after-cooled efficiency with a robust 1.5 m³ backhoe bucket for maximum productivity. Water-cooled reliability and 480 L/min hydraulic flow ensure consistent operation across demanding jobsites.
- Immediate Availability: Ships directly from Jiangsu—no manufacturing delays
- Proven Reach: 11,620 mm excavation radius, 8,080 mm maximum dig depth
- Complete Specs: 6,500 mm boom, 3,900 mm stick, 34.3 MPa hydraulic pressure
- Transport-Ready: 11,080 mm × 3,340 mm × 3,610 mm dimensions
- Fast Deployment: Skip lead times and mobilize to your site immediately
Backed by joint venture manufacturing standards and maintained for reliable performance, this excavator offers the power and precision Caterpillar is known for—available now for rapid logistics coordination throughout China and international markets.
| Specifications | Value |
|---|---|
| No. | 1032513 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 32420 |
| Bucket capacity (m³) | 1.5 |
| Boom length (mm) | 6500 |
| Rod length (mm) | 3900 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar 3306TA |
| Rated power (kw/rpm) | 165.5/1800 |
| Cooling mode | water-cooling |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 10.5 |
| Working form | Turbocharging; after-cooling |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 480 |
| Fuel Tank (L) | 560 |
| Engine Oil changes (L) | 30 |
| Coolant (L) | 45 |
| Hydraulic System (L) | 400 |
| Total transport length (mm) | 11080 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3610 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1260 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3500 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 600 |
| Total track width (mm) | 3190 |
| Track ground length (mm) | 4040 |
| Maximum digging depth (mm) | 8080 |
| Maximum excavation height (mm) | 10770 (Cutting) |
| Maximum unloading height (mm) | 7600 |
| Maximum vertical digging depth (mm) | 7230 |
| Maximum excavation radius of stop surface (mm) | 11620 |
| Travel speed (km/h) | 4.6 |
Overview
No.1032513
Brand Name：
CaterpillarModel Number：
330BYear：
2022
Location：
Jiangsu China
Pub Date：
