2016 Caterpillar 330C
Product Description
Built for high-output excavation, this 2016 Caterpillar 330C delivers 182kW of proven power through its 6-cylinder C9 engine. Operating at 30 tons with a 1.7m³ backhoe bucket, this machine tackles deep foundation work, mass excavation, and heavy demolition with precision. Maximum digging depth reaches 7,340mm while the 11,631mm reach handles large-scale site preparation without repositioning.
- Engine: Caterpillar C9, 8.8L displacement, 182kW rated power
- Capacity: 1.7m³ bucket, 35,108kg working weight
- Performance: 560L/min main pump flow, 34.3MPa system pressure
- Dimensions: 11,201mm transport length, 3,505mm rear turning radius
- Fuel: 617L tank for extended runtime
- Location: Currently in Guizhou, ready for deployment
Hydraulic responsiveness and Cat durability make this 330C suitable for infrastructure projects, mining support, and commercial development. Inspected, serviced, and prepared for immediate mobilization to your worksite.
| Specifications | Value |
|---|---|
| No. | 1019151 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 35108 |
| Bucket capacity (m³) | 1.7 |
| Country of origin | USA, Japan, Belgium, Brazil, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar C9 |
| Rated power (kw/rpm) | 182 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.8 |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 560 |
| Fuel Tank (L) | 617 |
| Hydraulic System (L) | 174 |
| Total transport length (mm) | 11201 |
| Total transport width (mm) | 3429 |
| Total transport height (mm) | 3734 |
| Minimum ground clearance (mm) | 488 |
| Back end turning radius (mm) | 3505 |
| Track gauge (mm) | 2591 |
| Track plate width (mm) | 864 |
| Total track width (mm) | 3429 |
| Track ground length (mm) | 4039 |
| Maximum excavation height (mm) | 8117 |
| Maximum unloading height (mm) | 7644 |
| Maximum vertical digging depth (mm) | 7340 |
| Maximum excavation radius of stop surface (mm) | 11631 |
| Travel speed (km/h) | 5.0 (Max) |
see more
Overview
No.1019151
Brand Name：
CaterpillarModel Number：
330CYear：
2016
Location：
Guizhou China
