2016 Caterpillar 330C
Product Description
Built for precision and reliability, this 2016 Caterpillar 330C excavator delivers exceptional operator control across demanding jobsites. With a 30-ton working weight and powerful Caterpillar C9 engine producing 182 kW, this machine combines robust digging force with refined handling characteristics that experienced operators appreciate.
- Spacious cabin design provides panoramic visibility across an 11,631 mm excavation radius
- Responsive hydraulic system features 560 l/min main pump flow for smooth, controlled movements
- 1.7 m³ backhoe bucket capacity handles substantial material volumes efficiently
- Stable 2,591 mm track gauge and 4,039 mm ground contact length ensure firm positioning on varied terrain
- Maximum digging depth of 7,340 mm reaches deep excavation requirements with precision
- Low-vibration 6-cylinder, 8.8L engine reduces operator fatigue during extended shifts
Currently located in Shenzhen, Guangdong, this joint venture-manufactured unit represents proven Caterpillar engineering. Intuitive joystick controls and excellent sightlines to bucket and tracks enable confident operation in confined spaces or high-production environments.
| Specifications | Value |
|---|---|
| No. | 1023980 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 35108 |
| Bucket capacity (m³) | 1.7 |
| Country of origin | USA, Japan, Belgium, Brazil, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar C9 |
| Rated power (kw/rpm) | 182 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.8 |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 560 |
| Fuel Tank (L) | 617 |
| Hydraulic System (L) | 174 |
| Total transport length (mm) | 11201 |
| Total transport width (mm) | 3429 |
| Total transport height (mm) | 3734 |
| Minimum ground clearance (mm) | 488 |
| Back end turning radius (mm) | 3505 |
| Track gauge (mm) | 2591 |
| Track plate width (mm) | 864 |
| Total track width (mm) | 3429 |
| Track ground length (mm) | 4039 |
| Maximum excavation height (mm) | 8117 |
| Maximum unloading height (mm) | 7644 |
| Maximum vertical digging depth (mm) | 7340 |
| Maximum excavation radius of stop surface (mm) | 11631 |
| Travel speed (km/h) | 5.0 (Max) |
see more
Overview
No.1023980
Brand Name：
CaterpillarModel Number：
330CYear：
2016
Location：
Guangdong China
Pub Date：
