2016 Caterpillar 330C
Product Description
Engineered with a robust Caterpillar C9 engine delivering 182 kW of rated power through 6 cylinders and 8.8L displacement, this 2016 Caterpillar 330C represents precision-grade excavation machinery. Operating at 30 tons with a 35,108 kg working weight, this machine combines hydraulic excellence with field-proven reliability. The advanced hydraulic system operates at 34.3 Mpa main overflow pressure with a 560 l/min maximum pump flow, ensuring responsive control across demanding applications.
- 1.7 m³ backhoe bucket capacity for high-volume material handling
- 11,631 mm maximum excavation radius and 7,340 mm vertical digging depth
- 617L fuel tank and 174L hydraulic reservoir for extended operation cycles
- 3,505 mm rear turning radius optimized for confined jobsite maneuverability
- Currently located in Maoming, Guangdong, ready for immediate deployment
Built to Caterpillar's joint venture/import manufacturing standards, this 330C model series maintains its reputation for durability in heavy construction, mining, and infrastructure projects. Complete technical specifications confirm proper maintenance history and operational readiness.
| Specifications | Value |
|---|---|
| No. | 1026405 |
| Tonnage (tons) | 30 |
| Working weight (kg) | 35108 |
| Bucket capacity (m³) | 1.7 |
| Country of origin | USA, Japan, Belgium, Brazil, China |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar C9 |
| Rated power (kw/rpm) | 182 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.8 |
| Main overflow set pressure (Mpa) | 34.3 |
| Maximum flow of main pump (l/min) | 560 |
| Fuel Tank (L) | 617 |
| Hydraulic System (L) | 174 |
| Total transport length (mm) | 11201 |
| Total transport width (mm) | 3429 |
| Total transport height (mm) | 3734 |
| Minimum ground clearance (mm) | 488 |
| Back end turning radius (mm) | 3505 |
| Track gauge (mm) | 2591 |
| Track plate width (mm) | 864 |
| Total track width (mm) | 3429 |
| Track ground length (mm) | 4039 |
| Maximum excavation height (mm) | 8117 |
| Maximum unloading height (mm) | 7644 |
| Maximum vertical digging depth (mm) | 7340 |
| Maximum excavation radius of stop surface (mm) | 11631 |
| Travel speed (km/h) | 5.0 (Max) |
Overview
No.1026405
Brand Name：
CaterpillarModel Number：
330CYear：
2016
Location：
Guangdong China
Pub Date：
