2013 Caterpillar 336DL
Product Description
Maximize productivity while minimizing capital expenditure with this 2013 Caterpillar 336DL excavator, currently available in Changsha, Hunan. Powered by the proven C9 ACERT engine delivering 200kW at 1900 rpm, this 36-ton workhorse combines Japanese engineering excellence with cost-effective pricing that undercuts new equipment by a significant margin. Operating weight of 35,020 kg provides exceptional stability for demanding applications, while the 1.5 m³ bucket capacity and robust hydraulic system—featuring 280 l/min main pump flow—ensure consistent performance on high-volume projects.
- Impressive reach specifications: 10,920 mm maximum excavation radius, 7,390 mm digging depth
- Powerful digging forces: 222 kN bucket force, 146 kN arm force
- Reliable water-cooled 6-cylinder engine with 8.8L displacement
- Comprehensive hydraulic capacity: 410L total system volume for extended operation
- 70% gradeability and 10 rpm rotation speed for versatile job site maneuverability
Invest intelligently in proven Caterpillar reliability without the premium new-equipment price tag. This machine delivers professional-grade performance at a fraction of replacement cost.
| Specifications | Value |
|---|---|
| No. | 1014405 |
| Tonnage (tons) | 36 |
| Working weight (kg) | 35020 |
| Bucket capacity (m³) | 1.5 |
| Boom length (mm) | 6500 |
| Rod length (mm) | 3200 |
| Country of origin | Japan/Xuzhou |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | C9ACERT |
| Rated power (kw/rpm) | 200/1900 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 110 x 127 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.8 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 222 |
| Rod digging force (kN) | 146 |
| Travel speed (km/h) | March 5th |
| Main overflow set pressure (Mpa) | 3.5 |
| Maximum flow of main pump (l/min) | 280 |
| Traveling Hydraulic Circuit (Mpa) | 3.5 |
| Rotary Hydraulic Circuit (Mpa) | 2.8 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 3.5 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 150 x 1151 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 170 x 1738 |
| Boom cylinders - Number × diameter × stroke (mm) | 150 x 1440 |
| Fuel Tank (L) | 620 |
| Hydraulic Tank (L) | 175 |
| Engine Oil changes (L) | 40 |
| Coolant (L) | 40 |
| Hydraulic System (L) | 410(including fuel tank) |
| Total transport length (mm) | 11150 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3340 |
| Full cab height (mm) | 3140 |
| Counterweight ground clearance (mm) | 1220 |
| Minimum ground clearance (mm) | 450 |
| Back end turning radius (mm) | 3500 |
| Total track length (mm) | 5020 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 700 |
| Total track width (mm) | 3290 |
| Track ground length (mm) | 4040 |
| Maximum digging depth (mm) | 7390 |
| Maximum excavation height (mm) | 10240 |
| Maximum unloading height (mm) | 7200 |
| Maximum vertical digging depth (mm) | 5830 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 10920 |
| Maximum effective digging depth (mm) | 7230 |
Overview
No.1014405
Brand Name：
CaterpillarModel Number：
336DLYear：
2013
Location：
Hunan China
Pub Date：
