2016 Caterpillar 336DL
Product Description
Built for heavy-duty excavation, this 2016 Caterpillar 336DL delivers 36 tons of operational power with a proven C9 ACERT engine rated at 200kW. Currently positioned in Shenzhen, Guangdong, this machine comes equipped with a 1.5m³ backhoe bucket, 6500mm boom, and 3200mm stick—configured for deep trenching, foundation work, and mass excavation projects requiring maximum reach and digging force.
- Maximum digging depth of 7390mm with 222kN bucket force tackles challenging ground conditions
- 10920mm excavation radius covers extensive work areas without repositioning
- Water-cooled 8.8L six-cylinder engine ensures reliable performance in demanding applications
- 280 L/min hydraulic flow supports responsive cycle times and efficient material handling
- 700mm track plates and 35,020kg working weight provide stability on varied terrain
Hydraulic systems are serviced and ready for immediate deployment. This crawler excavator handles site preparation, grading, demolition, and utility installation with proven Caterpillar durability. Specifications verified, documentation available for international shipping arrangements.
| Specifications | Value |
|---|---|
| No. | 1032520 |
| Tonnage (tons) | 36 |
| Working weight (kg) | 35020 |
| Bucket capacity (m³) | 1.5 |
| Boom length (mm) | 6500 |
| Rod length (mm) | 3200 |
| Country of origin | Japan/Xuzhou |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | C9ACERT |
| Rated power (kw/rpm) | 200/1900 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 110 x 127 |
| Number of cylinders (PCS) | 6 |
| Displacement (L) | 8.8 |
| Rotation speed (rpm) | 10 |
| Climbing ability (%) | 70/35 ° |
| Bucket digging force (kN) | 222 |
| Rod digging force (kN) | 146 |
| Travel speed (km/h) | March 5th |
| Main overflow set pressure (Mpa) | 3.5 |
| Maximum flow of main pump (l/min) | 280 |
| Traveling Hydraulic Circuit (Mpa) | 3.5 |
| Rotary Hydraulic Circuit (Mpa) | 2.8 |
| Hydraulic crushing pipeline is standard | no |
| Working Hydraulic Circuit (Mpa) | 3.5 |
| Pilot Oil Circuit (MPa) | 3.9 |
| Bucket cylinders - Number × diameter × stroke (mm) | 150 x 1151 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 170 x 1738 |
| Boom cylinders - Number × diameter × stroke (mm) | 150 x 1440 |
| Fuel Tank (L) | 620 |
| Hydraulic Tank (L) | 175 |
| Engine Oil changes (L) | 40 |
| Coolant (L) | 40 |
| Hydraulic System (L) | 410(including fuel tank) |
| Total transport length (mm) | 11150 |
| Total transport width (mm) | 3190 |
| Total transport height (mm) | 3340 |
| Full cab height (mm) | 3140 |
| Counterweight ground clearance (mm) | 1220 |
| Minimum ground clearance (mm) | 450 |
| Back end turning radius (mm) | 3500 |
| Total track length (mm) | 5020 |
| Track gauge (mm) | 2590 |
| Track plate width (mm) | 700 |
| Total track width (mm) | 3290 |
| Track ground length (mm) | 4040 |
| Maximum digging depth (mm) | 7390 |
| Maximum excavation height (mm) | 10240 |
| Maximum unloading height (mm) | 7200 |
| Maximum vertical digging depth (mm) | 5830 |
| Bulldozer lift or depth (mm) | No bulldozer |
| Dodging plate width × height (mm) | No bulldozer |
| Maximum excavation radius of stop surface (mm) | 10920 |
| Maximum effective digging depth (mm) | 7230 |
Overview
No.1032520
Brand Name：
CaterpillarModel Number：
336DLYear：
2016
Location：
Guangdong China
Pub Date：
