2015 Caterpillar 336FLH
Product Description
Available now in Fujian Ningde, this 2015 Caterpillar 336FLH delivers 36-ton performance without the factory wait. Powered by the Cat C9.3 ATAAC engine producing 224 kW, this hydraulic excavator meets EPA Tier 4 emission standards while maintaining robust productivity. Skip the lead times—this machine is ready for immediate deployment to your site.
- Operating Weight: 36,570–39,370 kg
- Bucket Capacity: 2.28 m³ for high-volume material handling
- Maximum Digging Depth: 10,740 mm
- Maximum Digging Height: 7,500 mm
- Hydraulic System: 578 L/min main pump flow with 35 MPa travel circuit
- Fuel Capacity: 620 L for extended runtime
- Travel Speed: 4.9 km/h with 295 kN maximum tractive force
Configured with adjustable boom options (2,550/3,200/3,900 mm) and rod lengths (6,180/6,500 mm), this joint-venture/import unit adapts to diverse jobsite requirements. Fast shipping from Fujian Ningde ensures rapid mobilization across Southeast Asia and beyond. Secure this proven Caterpillar excavator today.
| Specifications | Value |
|---|---|
| No. | 1014833 |
| Tonnage (tons) | 36 |
| Working weight (kg) | 36570-39370 |
| Bucket capacity (m³) | 2.28 |
| Boom length (mm) | 2550/3200/3900 |
| Rod length (mm) | 6180/6500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar Cat C9.3(ATAAC) |
| Rated power (kw/rpm) | 224 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 115 x 149 |
| Displacement (L) | 9.3 |
| Working form | Air-to-air cooling meets EPA Tier 4 (US Environmental Protection Agency Phase 4) emission standards |
| Rotation speed (rpm) | 9.2 |
| Maximum tractive force (kN) | 295 |
| Travel speed (km/h) | 4.9 |
| Maximum flow of main pump (l/min) | 578 |
| Traveling Hydraulic Circuit (Mpa) | |35 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Pilot pump flow (L/min) | 4.1 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-160 x 1356 |
| Fuel Tank (L) | 620 |
| Coolant (L) | 56 |
| Total transport length (mm) | 11170 |
| Total transport width (mm) | 3290/3390/3440 |
| Counterweight ground clearance (mm) | 5020 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3500 |
| Total track length (mm) | |700/800/850 |
| Maximum digging depth (mm) | 10740 |
| Maximum excavation height (mm) | 7500 |
| Maximum unloading height (mm) | 7610 |
