2016 Caterpillar 336FLH










Product Description
Investing in proven machinery means choosing a brand that stands behind its equipment long after the sale. This 2016 Caterpillar 336FLH excavator, located in Foshan, Guangdong, represents exactly that commitment. With a 36-ton operating weight and powered by the reliable Cat C9.3 engine delivering 224 kW, this machine combines substantial digging force with the parts availability and service network that only Caterpillar provides.
Key specifications include:
- Maximum digging depth of 10,740mm with 2.28m³ bucket capacity
- EPA Tier 4 compliant air-to-air cooling system
- Hydraulic flow rate of 578 L/min for responsive operation
- Multiple boom configurations (2550/3200/3900mm) for versatility
Caterpillar's global parts distribution network ensures minimal downtime, while strong resale values protect your investment. Backed by comprehensive technical documentation and widespread dealer support throughout China, this 336FLH offers the operational confidence that keeps projects on schedule and budgets intact. Built for demanding forestry and heavy construction applications, it delivers the durability that has made Caterpillar the industry standard.
| Specifications | Value |
|---|---|
| No. | 1006202 |
| Tonnage (tons) | 36 |
| Working weight (kg) | 36570-39370 |
| Bucket capacity (m³) | 2.28 |
| Boom length (mm) | 2550/3200/3900 |
| Rod length (mm) | 6180/6500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar Cat C9.3(ATAAC) |
| Rated power (kw/rpm) | 224 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 115 x 149 |
| Displacement (L) | 9.3 |
| Working form | Air-to-air cooling meets EPA Tier 4 (US Environmental Protection Agency Phase 4) emission standards |
| Rotation speed (rpm) | 9.2 |
| Maximum tractive force (kN) | 295 |
| Travel speed (km/h) | 4.9 |
| Maximum flow of main pump (l/min) | 578 |
| Traveling Hydraulic Circuit (Mpa) | |35 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Pilot pump flow (L/min) | 4.1 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-160 x 1356 |
| Fuel Tank (L) | 620 |
| Coolant (L) | 56 |
| Total transport length (mm) | 11170 |
| Total transport width (mm) | 3290/3390/3440 |
| Counterweight ground clearance (mm) | 5020 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3500 |
| Total track length (mm) | |700/800/850 |
| Maximum digging depth (mm) | 10740 |
| Maximum excavation height (mm) | 7500 |
| Maximum unloading height (mm) | 7610 |
Overview
No.1006202
Brand Name:
CaterpillarModel Number:
336FLHYear:
2016
Location:
Guangdong China
Pub Date:
