2016 Caterpillar 336FLH
Product Description
Proven performance meets unwavering reliability in this 2016 Caterpillar 336FLH hydraulic excavator, currently located in Luzhou, Sichuan. Operating at 36 tons with a working weight range of 36,570-39,370 kg, this machine demonstrates Caterpillar's commitment to engineering excellence that stands the test of time. Powered by the Cat C9.3 ATAAC engine delivering 224 kW, this workhorse combines robust traditional power with EPA Tier 4 compliant air-to-air cooling technology for efficient, responsible operation.
Built to withstand demanding jobsites, key specifications include:
- Maximum digging depth of 10,740 mm with 2.28 m³ bucket capacity
- Exceptional reach: 7,610 mm maximum unloading height
- Hydraulic system: 578 L/min main pump flow for consistent performance
- 9.2 rpm rotation speed with 295 kN maximum tractive force
- 620L fuel capacity supporting extended operation cycles
After years in service, this 336FLH continues delivering the productivity and durability that made Caterpillar the industry standard. A proven workhorse ready for your toughest excavation challenges.
| Specifications | Value |
|---|---|
| No. | 1017907 |
| Tonnage (tons) | 36 |
| Working weight (kg) | 36570-39370 |
| Bucket capacity (m³) | 2.28 |
| Boom length (mm) | 2550/3200/3900 |
| Rod length (mm) | 6180/6500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar Cat C9.3(ATAAC) |
| Rated power (kw/rpm) | 224 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 115 x 149 |
| Displacement (L) | 9.3 |
| Working form | Air-to-air cooling meets EPA Tier 4 (US Environmental Protection Agency Phase 4) emission standards |
| Rotation speed (rpm) | 9.2 |
| Maximum tractive force (kN) | 295 |
| Travel speed (km/h) | 4.9 |
| Maximum flow of main pump (l/min) | 578 |
| Traveling Hydraulic Circuit (Mpa) | |35 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Pilot pump flow (L/min) | 4.1 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-160 x 1356 |
| Fuel Tank (L) | 620 |
| Coolant (L) | 56 |
| Total transport length (mm) | 11170 |
| Total transport width (mm) | 3290/3390/3440 |
| Counterweight ground clearance (mm) | 5020 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3500 |
| Total track length (mm) | |700/800/850 |
| Maximum digging depth (mm) | 10740 |
| Maximum excavation height (mm) | 7500 |
| Maximum unloading height (mm) | 7610 |
Overview
No.1017907
Brand Name：
CaterpillarModel Number：
336FLHYear：
2016
Location：
Sichuan China
Pub Date：
