2016 Caterpillar 336FLH
Product Description
With a working weight of 36,570-39,370 kg and a bucket capacity of 2.28 m³, this 2016 Caterpillar 336FLH excavator is ready for immediate deployment from 广东河源. Available now, you can skip the factory lead times and get to work faster. Powered by a Caterpillar Cat C9.3 engine with 224 kW, it ensures reliable performance and meets EPA Tier 4 emission standards. The machine offers a maximum digging depth of 10,740 mm and a maximum unloading height of 7,610 mm, making it versatile for various construction needs. Its travel speed of 4.9 km/h and maximum tractive force of 295 kN enhance on-site mobility and efficiency.
- Working weight: 36,570-39,370 kg
- Bucket capacity: 2.28 m³
- Engine: Caterpillar Cat C9.3, 224 kW
- Maximum digging depth: 10,740 mm
- Travel speed: 4.9 km/h
- Location: 广东河源
| Specifications | Value |
|---|---|
| No. | 995310 |
| Tonnage (tons) | 36 |
| Working weight (kg) | 36570-39370 |
| Bucket capacity (m³) | 2.28 |
| Boom length (mm) | 2550/3200/3900 |
| Rod length (mm) | 6180/6500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar Cat C9.3(ATAAC) |
| Rated power (kw/rpm) | 224 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 115 x 149 |
| Displacement (L) | 9.3 |
| Working form | Air-to-air cooling meets EPA Tier 4 (US Environmental Protection Agency Phase 4) emission standards |
| Rotation speed (rpm) | 9.2 |
| Maximum tractive force (kN) | 295 |
| Travel speed (km/h) | 4.9 |
| Maximum flow of main pump (l/min) | 578 |
| Traveling Hydraulic Circuit (Mpa) | |35 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Pilot pump flow (L/min) | 4.1 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-160 x 1356 |
| Fuel Tank (L) | 620 |
| Coolant (L) | 56 |
| Total transport length (mm) | 11170 |
| Total transport width (mm) | 3290/3390/3440 |
| Counterweight ground clearance (mm) | 5020 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3500 |
| Total track length (mm) | |700/800/850 |
| Maximum digging depth (mm) | 10740 |
| Maximum excavation height (mm) | 7500 |
| Maximum unloading height (mm) | 7610 |
see more
Overview
No.995310
Brand Name：
CaterpillarModel Number：
336FLHYear：
2016
Location：
Guangdong China
Pub Date：
