2016 Caterpillar 336FLH
Product Description
Available now in 广西来宾, this 2016 Caterpillar 336FLH forestry excavator eliminates factory wait times and delivers immediate deployment to your operation. Powered by a Cat C9.3 ATAAC engine producing 224 kW, this 36-ton machine combines proven hydraulic performance with EPA Tier 4 compliance for demanding forestry applications.
- Working weight: 36,570-39,370 kg with robust forestry configuration
- Maximum digging depth of 10,740 mm and reach height of 7,500 mm
- High-flow hydraulics: 578 L/min main pump capacity for responsive attachment control
- Multiple boom options (2,550/3,200/3,900 mm) and arm lengths (6,180/6,500 mm)
- Water-cooled 9.3L displacement engine with air-to-air aftercooling
- 620L fuel capacity for extended operating shifts
Skip the lead times associated with new equipment orders. Fast deployment from 广西来宾 means your crew can begin productive work immediately. Joint venture quality construction ensures reliability in challenging forestry environments where downtime costs money.
| Specifications | Value |
|---|---|
| No. | 998068 |
| Tonnage (tons) | 36 |
| Working weight (kg) | 36570-39370 |
| Bucket capacity (m³) | 2.28 |
| Boom length (mm) | 2550/3200/3900 |
| Rod length (mm) | 6180/6500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar Cat C9.3(ATAAC) |
| Rated power (kw/rpm) | 224 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 115 x 149 |
| Displacement (L) | 9.3 |
| Working form | Air-to-air cooling meets EPA Tier 4 (US Environmental Protection Agency Phase 4) emission standards |
| Rotation speed (rpm) | 9.2 |
| Maximum tractive force (kN) | 295 |
| Travel speed (km/h) | 4.9 |
| Maximum flow of main pump (l/min) | 578 |
| Traveling Hydraulic Circuit (Mpa) | |35 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Pilot pump flow (L/min) | 4.1 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-160 x 1356 |
| Fuel Tank (L) | 620 |
| Coolant (L) | 56 |
| Total transport length (mm) | 11170 |
| Total transport width (mm) | 3290/3390/3440 |
| Counterweight ground clearance (mm) | 5020 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3500 |
| Total track length (mm) | |700/800/850 |
| Maximum digging depth (mm) | 10740 |
| Maximum excavation height (mm) | 7500 |
| Maximum unloading height (mm) | 7610 |
