2019 Caterpillar 336FLH
Product Description
Investing in proven machinery means choosing a brand that stands behind its equipment long after the sale. This 2019 Caterpillar 336FLH excavator, currently located in Changsha, Hunan, represents exactly that commitment to reliability. With a 36-ton operating weight and powered by the robust Cat C9.3 engine delivering 224 kW, this machine combines substantial performance with the parts availability and service network that only Caterpillar provides.
Key specifications include:
- Working weight: 36,570-39,370 kg with exceptional stability
- Maximum digging depth of 10,740 mm for demanding applications
- 2.28 m³ bucket capacity for productive cycle times
- EPA Tier 4 compliant engine with air-to-air cooling technology
- 578 L/min hydraulic flow for responsive operation
Caterpillar's global parts distribution network ensures minimal downtime, while strong resale values protect your investment. Backed by comprehensive dealer support throughout China and worldwide, this 336FLH offers the dependability that keeps projects on schedule and budgets intact. Choose equipment that maintains its value and keeps working when you need it most.
| Specifications | Value |
|---|---|
| No. | 1007101 |
| Tonnage (tons) | 36 |
| Working weight (kg) | 36570-39370 |
| Bucket capacity (m³) | 2.28 |
| Boom length (mm) | 2550/3200/3900 |
| Rod length (mm) | 6180/6500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar Cat C9.3(ATAAC) |
| Rated power (kw/rpm) | 224 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 115 x 149 |
| Displacement (L) | 9.3 |
| Working form | Air-to-air cooling meets EPA Tier 4 (US Environmental Protection Agency Phase 4) emission standards |
| Rotation speed (rpm) | 9.2 |
| Maximum tractive force (kN) | 295 |
| Travel speed (km/h) | 4.9 |
| Maximum flow of main pump (l/min) | 578 |
| Traveling Hydraulic Circuit (Mpa) | |35 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Pilot pump flow (L/min) | 4.1 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1-160 x 1356 |
| Fuel Tank (L) | 620 |
| Coolant (L) | 56 |
| Total transport length (mm) | 11170 |
| Total transport width (mm) | 3290/3390/3440 |
| Counterweight ground clearance (mm) | 5020 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3500 |
| Total track length (mm) | |700/800/850 |
| Maximum digging depth (mm) | 10740 |
| Maximum excavation height (mm) | 7500 |
| Maximum unloading height (mm) | 7610 |
Overview
No.1007101
Brand Name：
CaterpillarModel Number：
336FLHYear：
2019
Location：
Hunan China
Pub Date：
