2016 Caterpillar 340D2L
Product Description
Built for high-output excavation work, this 2016 Caterpillar 340D2L delivers 208 kW of reliable power through its Cat C9 engine with turbocharger aftercooler. Currently located in Jinan, Shandong, this 40-ton machine handles deep foundation work, large-scale earthmoving, and demolition projects with a maximum digging depth of 7,190 mm and excavation radius of 10,830 mm.
Equipped with a 1.9 m³ backhoe bucket, 6,500 mm boom, and 2,800 mm stick, it generates 210 kN bucket digging force and 185 kN stick digging force for breaking through compacted soil and rock. The hydraulic system operates at 35 MPa with 281 L/min main pump flow, ensuring smooth, responsive control across all functions. Track width of 600 mm and 3,490 mm tail swing radius provide stability on uneven terrain while maintaining maneuverability in confined spaces.
- Working weight: 38,900-41,500 kg
- Maximum excavation height: 10,330 mm
- Travel speed: 4.6 km/h
- Fuel capacity: 175 L
- Hydraulic tank: 620 L
Ready for immediate deployment on your next project.
| Specifications | Value |
|---|---|
| No. | 1011245 |
| Tonnage (tons) | 40 |
| Working weight (kg) | 38900~41500 |
| Bucket capacity (m³) | 1.9 |
| Boom length (mm) | 6500 |
| Rod length (mm) | 2800 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CatC9 |
| Rated power (kw/rpm) | 208 |
| Cylinder diameter × stroke (mm) | 112 x 149 |
| Displacement (L) | 8.8 |
| Working form | Direct injection fuel system with turbocharger aftercooler |
| Rotation speed (rpm) | 8.3 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 210 |
| Rod digging force (kN) | 185 |
| Maximum tractive force (kN) | 300 |
| Travel speed (km/h) | 4.6 |
| Turning torque (Nm) | 109 |
| Main overflow set pressure (Mpa) | 35 |
| Maximum flow of main pump (l/min) | 281 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Pilot Oil Circuit (MPa) | 4 |
| Pilot pump flow (L/min) | 40 |
| Bucket cylinders - Number × diameter × stroke (mm) | 150 x 1151 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 170 x 1738 |
| Boom cylinders - Number × diameter × stroke (mm) | 150 x 1440 |
| Fuel Tank (L) | 175 |
| Hydraulic Tank (L) | 620 |
| Engine Oil changes (L) | 41 |
| Coolant (L) | 40 |
| Hydraulic System (L) | 410 |
| Total transport length (mm) | 11170 |
| Total transport width (mm) | 3620 |
| Total transport height (mm) | 3630 |
| Full cab height (mm) | 3360 |
| Counterweight ground clearance (mm) | 1450 |
| Minimum ground clearance (mm) | 742 |
| Back end turning radius (mm) | 3490 |
| Total track length (mm) | 5060 |
| Track gauge (mm) | 2920 |
| Track plate width (mm) | 600 |
| Maximum digging depth (mm) | 7190 |
| Maximum excavation height (mm) | 10330 |
| Maximum unloading height (mm) | 7000 |
| Maximum vertical digging depth (mm) | 5460 |
| Maximum excavation radius of stop surface (mm) | 10830 |
| Maximum effective digging depth (mm) | 6370 |
