2016 Caterpillar 340D2L
Product Description
Available now in Jinan, Shandong—skip the factory lead times and get this 40-ton Caterpillar 340D2L excavator deployed to your site fast. Built in 2016 with a proven Cat C9 engine delivering 208 kW, this machine combines the reliability of joint venture manufacturing with the performance specs your operation demands.
Equipped with a 1.9 m³ backhoe bucket, 6500mm boom, and 2800mm arm, it reaches a maximum digging depth of 7190mm and an excavation radius of 10830mm. Hydraulic power flows at 281 L/min through a 35 MPa system, generating 210 kN bucket digging force and 185 kN arm force. The direct injection turbocharged engine and 620L hydraulic tank ensure consistent output across long shifts.
Key specifications:
- Operating weight: 38,900–41,500 kg
- Maximum digging height: 10,330mm
- Travel speed: 4.6 km/h with 70% gradeability
- Fuel capacity: 175L for extended runtime
- Transport dimensions: 11,170 × 3,620 × 3,630mm
Ready for immediate logistics coordination from Shandong. Contact Fair Trade Machinery today for fast international shipping and documentation support.
| Specifications | Value |
|---|---|
| No. | 1011246 |
| Tonnage (tons) | 40 |
| Working weight (kg) | 38900~41500 |
| Bucket capacity (m³) | 1.9 |
| Boom length (mm) | 6500 |
| Rod length (mm) | 2800 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CatC9 |
| Rated power (kw/rpm) | 208 |
| Cylinder diameter × stroke (mm) | 112 x 149 |
| Displacement (L) | 8.8 |
| Working form | Direct injection fuel system with turbocharger aftercooler |
| Rotation speed (rpm) | 8.3 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 210 |
| Rod digging force (kN) | 185 |
| Maximum tractive force (kN) | 300 |
| Travel speed (km/h) | 4.6 |
| Turning torque (Nm) | 109 |
| Main overflow set pressure (Mpa) | 35 |
| Maximum flow of main pump (l/min) | 281 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Pilot Oil Circuit (MPa) | 4 |
| Pilot pump flow (L/min) | 40 |
| Bucket cylinders - Number × diameter × stroke (mm) | 150 x 1151 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 170 x 1738 |
| Boom cylinders - Number × diameter × stroke (mm) | 150 x 1440 |
| Fuel Tank (L) | 175 |
| Hydraulic Tank (L) | 620 |
| Engine Oil changes (L) | 41 |
| Coolant (L) | 40 |
| Hydraulic System (L) | 410 |
| Total transport length (mm) | 11170 |
| Total transport width (mm) | 3620 |
| Total transport height (mm) | 3630 |
| Full cab height (mm) | 3360 |
| Counterweight ground clearance (mm) | 1450 |
| Minimum ground clearance (mm) | 742 |
| Back end turning radius (mm) | 3490 |
| Total track length (mm) | 5060 |
| Track gauge (mm) | 2920 |
| Track plate width (mm) | 600 |
| Maximum digging depth (mm) | 7190 |
| Maximum excavation height (mm) | 10330 |
| Maximum unloading height (mm) | 7000 |
| Maximum vertical digging depth (mm) | 5460 |
| Maximum excavation radius of stop surface (mm) | 10830 |
| Maximum effective digging depth (mm) | 6370 |
