2019 Caterpillar 340D2L
Product Description
Powered by a 208 kW Cat C9 engine with turbocharged aftercooler technology, this 2019 Caterpillar 340D2L delivers exceptional operator control across demanding excavation tasks. Operating at 40 tons with a 1.9 m³ bucket capacity, this machine combines raw digging force—210 kN bucket and 185 kN stick—with refined hydraulic precision through its 281 L/min main pump flow and 35 MPa system pressure.
Operator-focused engineering defines this model's performance advantages:
- Spacious cab design with panoramic visibility covering the full 10,830 mm excavation radius
- Stable platform with 2,920 mm track gauge and 600 mm grouser plates for confident operation on slopes up to 70%
- Responsive 8.3 rpm swing speed and 4 MPa pilot circuit enabling smooth, fatigue-reducing control
- Maximum digging depth of 7,190 mm and reach height of 10,330 mm from a secure operating position
- Low-vibration powertrain reducing operator strain during extended shifts
Currently located in Shaoxing, Zhejiang, this joint-venture manufactured excavator represents proven Cat reliability with import-grade build quality for high-production earthmoving operations.
| Specifications | Value |
|---|---|
| No. | 1016684 |
| Tonnage (tons) | 40 |
| Working weight (kg) | 38900~41500 |
| Bucket capacity (m³) | 1.9 |
| Boom length (mm) | 6500 |
| Rod length (mm) | 2800 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CatC9 |
| Rated power (kw/rpm) | 208 |
| Cylinder diameter × stroke (mm) | 112 x 149 |
| Displacement (L) | 8.8 |
| Working form | Direct injection fuel system with turbocharger aftercooler |
| Rotation speed (rpm) | 8.3 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 210 |
| Rod digging force (kN) | 185 |
| Maximum tractive force (kN) | 300 |
| Travel speed (km/h) | 4.6 |
| Turning torque (Nm) | 109 |
| Main overflow set pressure (Mpa) | 35 |
| Maximum flow of main pump (l/min) | 281 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 28 |
| Pilot Oil Circuit (MPa) | 4 |
| Pilot pump flow (L/min) | 40 |
| Bucket cylinders - Number × diameter × stroke (mm) | 150 x 1151 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 170 x 1738 |
| Boom cylinders - Number × diameter × stroke (mm) | 150 x 1440 |
| Fuel Tank (L) | 175 |
| Hydraulic Tank (L) | 620 |
| Engine Oil changes (L) | 41 |
| Coolant (L) | 40 |
| Hydraulic System (L) | 410 |
| Total transport length (mm) | 11170 |
| Total transport width (mm) | 3620 |
| Total transport height (mm) | 3630 |
| Full cab height (mm) | 3360 |
| Counterweight ground clearance (mm) | 1450 |
| Minimum ground clearance (mm) | 742 |
| Back end turning radius (mm) | 3490 |
| Total track length (mm) | 5060 |
| Track gauge (mm) | 2920 |
| Track plate width (mm) | 600 |
| Maximum digging depth (mm) | 7190 |
| Maximum excavation height (mm) | 10330 |
| Maximum unloading height (mm) | 7000 |
| Maximum vertical digging depth (mm) | 5460 |
| Maximum excavation radius of stop surface (mm) | 10830 |
| Maximum effective digging depth (mm) | 6370 |
see more
Overview
No.1016684
Brand Name：
CaterpillarModel Number：
340D2LYear：
2019
Location：
Zhejiang China
Pub Date：
