2022 Caterpillar 349D2
Product Description
Available for sale: Used Caterpillar 349D2 hydraulic excavator, manufactured in 2022 and currently located in Jilin Province, China. This heavy-duty excavator represents Caterpillar's commitment to durability and performance in demanding applications.
The Cat 349D2 is engineered for high-production excavation, demolition, and material handling operations. This model features robust construction, efficient fuel consumption, and the reliability expected from Caterpillar's D2 series. Suitable for mining, quarrying, and large-scale earthmoving projects.
- Year of Manufacture: 2022
- Make: Caterpillar
- Model: 349D2
- Current Location: Jilin, China
- Category: Hydraulic Excavator
For detailed specifications, current operating hours, service history, and pricing information, please contact our sales team. Inspection welcomed by appointment.
| Specifications | Value |
|---|---|
| No. | 1115727 |
| Tonnage (tons) | 49 |
| Working weight (kg) | 45260 |
| Bucket capacity (m³) | 3.2 |
| Boom length (mm) | 6900 |
| Rod length (mm) | 3350 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Cat C13 ACERT |
| Rated power (kw/rpm) | 289 |
| Cylinder diameter × stroke (mm) | 130 x 157 |
| Displacement (L) | 12.5 |
| Rotation speed (rpm) | 8.7 |
| Climbing ability (%) | 70 |
| Bucket digging force (kN) | 267 |
| Rod digging force (kN) | 201 |
| Maximum tractive force (kN) | 338 |
| Travel speed (km/h) | 4.5 |
| Turning torque (Nm) | 149 |
| Main overflow set pressure (Mpa) | 35 |
| Maximum flow of main pump (l/min) | 734 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 31.4 |
| Pilot Oil Circuit (MPa) | 4.11 |
| Pilot pump flow (L/min) | 43 |
| Bucket cylinders - Number × diameter × stroke (mm) | 160 x 1356 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 190 x 1778 |
| Boom cylinders - Number × diameter × stroke (mm) | 160 x 1575 |
| Fuel Tank (L) | 705 |
| Hydraulic Tank (L) | 243 |
| Engine Oil changes (L) | 42 |
| Coolant (L) | 35.5 |
| Hydraulic System (L) | 570 |
| Total transport length (mm) | 11940 |
| Total transport width (mm) | 3340 |
| Total transport height (mm) | 3690 |
| Full cab height (mm) | 3640 |
| Counterweight ground clearance (mm) | 1320 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3770 |
| Total track length (mm) | 5070 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 750 |
| Maximum digging depth (mm) | 7600 |
| Maximum excavation height (mm) | 10800 |
| Maximum unloading height (mm) | 7470 |
| Maximum vertical digging depth (mm) | 6300 |
| Maximum excavation radius of stop surface (mm) | 11660 |
| Maximum effective digging depth (mm) | 7460 |
