2020 Caterpillar 349EL
Product Description
Built to endure the most demanding job sites, this 2020 Caterpillar 349EL is a proven workhorse with years of reliable performance behind it — and plenty more ahead. Powered by a Caterpillar Cat C13 ACERT engine producing 301 kW, it meets US Tier 4 emission standards while delivering the raw output serious excavation demands. At 47,800–53,300 kg working weight and a 3.1 m³ bucket capacity, this 49-ton machine handles heavy material movement without compromise.
- Engine: Cat C13 ACERT, 301 kW, water-cooled, 12.5L displacement
- Bucket digging force: 268 kN | Rod digging force: 184 kN
- Maximum digging depth: 8,180 mm | Maximum digging radius: 12,120 mm
- Maximum tractive force: 335 kN | Travel speed: 4.7 km/h
- Hydraulic system capacity: 570 L | Main pump max flow: 770 L/min
- Fuel tank: 720 L — built for long shifts with minimal downtime
- Track plate width options: 600 / 750 / 900 mm for varied terrain
- Location: Guangdong, China — available for international export
Four years of field-proven durability make this 349EL a smart acquisition for contractors who need a large excavator they can trust from day one. Inspect it, run it, and put it to work.
| Specifications | Value |
|---|---|
| No. | 1074090 |
| Tonnage (tons) | 49 |
| Working weight (kg) | 47800-53300 |
| Bucket capacity (m³) | 3.1 |
| Boom length (mm) | 6900/6550 |
| Rod length (mm) | 3900/3350/3000/2500 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | Caterpillar Cat C13 ACERT |
| Rated power (kw/rpm) | 301 |
| Cooling mode | water-cooling |
| Cylinder diameter × stroke (mm) | 130 x 157 |
| Displacement (L) | 12.5 |
| Working form | Meet US Tier4 emission standards. |
| Rotation speed (rpm) | 8.7 |
| Bucket digging force (kN) | 268 |
| Rod digging force (kN) | 184 |
| Maximum tractive force (kN) | 335 |
| Travel speed (km/h) | 4.7 |
| Maximum flow of main pump (l/min) | 770 |
| Traveling Hydraulic Circuit (Mpa) | 35 |
| Rotary Hydraulic Circuit (Mpa) | 27.5 |
| Pilot Oil Circuit (MPa) | 4.12 |
| Pilot pump flow (L/min) | 27 |
| Bucket cylinders - Number × diameter × stroke (mm) | 1 x 170 x 1396 |
| Bucket rod cylinders - Number × diameter × stroke (mm) | 1 x 190 x 1758 |
| Boom cylinders - Number × diameter × stroke (mm) | 2 x 170 x 1524 |
| Fuel Tank (L) | 720 |
| Hydraulic Tank (L) | 407 |
| Engine Oil changes (L) | 43 |
| Coolant (L) | 50 |
| Hydraulic System (L) | 570 |
| Total transport length (mm) | 11930 |
| Total transport width (mm) | 3340/3490/3640 |
| Total transport height (mm) | 3670 |
| Full cab height (mm) | 3220 |
| Counterweight ground clearance (mm) | 1280 |
| Minimum ground clearance (mm) | 510 |
| Back end turning radius (mm) | 3760 |
| Total track length (mm) | 5370 |
| Track gauge (mm) | 2740 |
| Track plate width (mm) | 600/750/900 |
| Total track width (mm) | 3340/3490/3640 |
| Maximum digging radius (mm) | 12120 |
| Maximum digging depth (mm) | 8180 |
| Maximum excavation height (mm) | 10730 |
| Maximum unloading height (mm) | 7450 |
| Maximum vertical digging depth (mm) | 5890 |
| Maximum effective digging depth (mm) | 8050 |
see more
Overview
No.1074090
Brand Name：
CaterpillarModel Number：
349ELYear：
2020
Location：
Guangdong China
Pub Date：
