2016 Caterpillar E200B
Product Description
Powered by the CATERPILLAR 3116 engine, delivering 88 kW at 1800 rpm, this 20-ton excavator from Caterpillar's E200B series ensures robust performance and reliability. With a working weight of 18,800 kg, it is designed for heavy-duty tasks. The hydraulic system, with a capacity of 250 liters, supports precise and efficient operations.
- Engine: CATERPILLAR 3116, 88 kW/1800 rpm
- Hydraulic System: 250 L
- Bucket Capacity: 0.57/0.38/1.1 m³
- Travel Speed: 5 km/h
- Fuel Tank: 280 L
- Total Transport Dimensions: 9705 mm (L) x 2800 mm (W) x 3015 mm (H)
Engineered for superior digging and loading, the E200B offers a maximum digging depth of 5680 mm and a maximum unloading height of 6050 mm. Its robust design, including a track gauge of 2200 mm and a track plate width of 600 mm, provides stability and maneuverability on various terrains. Located in 广东深圳, this machine is ready to meet your construction needs with its advanced features and durable build.
| Specifications | Value |
|---|---|
| No. | 1033482 |
| Tonnage (tons) | 20 |
| Working weight (kg) | 18800 |
| Bucket capacity (m³) | 0.57/0.38/1.1 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CATERPILLAR 3116 |
| Rated power (kw/rpm) | 88/1800 |
| Displacement (L) | 6.6 |
| Ground specific pressure (Kpa) | 43.4 |
| Travel speed (km/h) | 5 |
| Fuel Tank (L) | 280 |
| Engine Oil changes (L) | 15 |
| Coolant (L) | 23 |
| Hydraulic System (L) | 250 |
| Total transport length (mm) | 9705 |
| Total transport width (mm) | 2800 |
| Total transport height (mm) | 3015 |
| Full cab height (mm) | 2830 |
| Counterweight ground clearance (mm) | 1030 |
| Minimum ground clearance (mm) | 465 |
| Back end turning radius (mm) | 2750 |
| Track gauge (mm) | 2200 |
| Track plate width (mm) | 600 |
| Maximum digging depth (mm) | 5680 |
| Maximum excavation height (mm) | 8880 |
| Maximum unloading height (mm) | 6050 |
| Maximum vertical digging depth (mm) | 4820 |
| Maximum excavation radius of stop surface (mm) | 8850 |
Overview
No.1033482
Brand Name：
CaterpillarModel Number：
E200BYear：
2016
Location：
Guangdong China
Pub Date：
