2017 Caterpillar M315







Product Description
This 2017 Caterpillar M315 wheeled excavator offers proven performance for urban construction and infrastructure projects. Manufactured by Caterpillar, a globally recognized leader in heavy equipment, this machine combines mobility with operational efficiency. Currently located in Sichuan, China, it is available for immediate inspection and purchase.
Key Features:
- Year: 2017
- Model: Caterpillar M315
- Type: Wheeled Excavator
- Location: Sichuan Province, China
- Condition: Used
The M315 wheeled excavator is designed for versatility in road construction, utility work, and material handling applications. Its wheeled configuration enables rapid relocation between job sites without requiring transportation equipment. This unit represents a cost-effective solution for contractors seeking reliable Caterpillar engineering at a competitive price point.
| Specifications | Value |
|---|---|
| No. | 1082443 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 16000 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | cat 3054TA |
| Rated power (kw/rpm) | 92.5 |
| Total displacement (L) | 4 |
| Forward speed (Km/h) | 34 |
| Main overflow set pressure (Mpa) | 33 |
| Fuel Tank (L) | 240 |
| Hydraulic System (L) | 210 |
| Total transport width (mm) | 2500 |
| Full cab height (mm) | 3080 |
| Counterweight ground clearance (mm) | 1262 |
| Wheelbase (mm) | 2500 |
| Total tire outside width (mm) | 2500 |
| Minimum ground clearance (mm) | 375 |
| Maximum excavation radius (mm) | 7950 |
| Maximum digging depth (mm) | 4650 |
| Maximum excavation height (mm) | 8180 |
| Maximum unloading height (mm) | 5940 |
| Maximum vertical digging depth (mm) | 2510 |
Overview
No.1082443
Brand Name:
CaterpillarModel Number:
M315Year:
2017
Location:
Sichuan China
Pub Date:
