HOME>>Caterpillar>>Caterpillar M315D

2011 Caterpillar M315D

1/9
Buy Caterpillar M315D Used Excavator / 1
Buy Caterpillar M315D Used Excavator / 2
Buy Caterpillar M315D Used Excavator / 3
Buy Caterpillar M315D Used Excavator / 4
Buy Caterpillar M315D Used Excavator / 5
Buy Caterpillar M315D Used Excavator / 6
Buy Caterpillar M315D Used Excavator / 7
Buy Caterpillar M315D Used Excavator / 8
Buy Caterpillar M315D Used Excavator / 9

Product Description

Featuring a 15-ton working weight and powered by the CATERPILLAR C4.4 Acert engine, this 2011 Caterpillar M315D excavator, located in Fujian, China, offers reliable performance and robust construction. With a bucket capacity of 0.78/0.34/1.1 m³, it handles diverse excavation tasks efficiently.

  • Ensures smooth and stable operation with a total displacement of 4.4 L and a rated power of 108 kW at 2000 rpm.
  • Equipped with a full cab height of 3150 mm, providing operators with excellent visibility and comfort.
  • Boasts a forward speed of 34 km/h and a rotation speed of 10.5 rpm, enhancing maneuverability on various terrains.
  • Offers a maximum digging depth of 5590 mm and a maximum unloading height of 6950 mm, ideal for deep and high-reach operations.
  • Designed with a minimum ground clearance of 370 mm and a back end turning radius of 2215 mm, ensuring easy navigation and stability.
SpecificationsValue
No.1085752
Tonnage (tons)15
Working weight (kg)17900
Bucket capacity (m³)0.78/0.34/1.1
powerTraditional power
manufacturerJoint venture/Import
bucketbackhoe
Engine typeCATERPILLAR C4.4 Acert
Rated power (kw/rpm)108(101)/2000
Total displacement (L)4.4
Forward speed (Km/h)34
Rotation speed (rpm)10.5
Main overflow set pressure (Mpa)35
Fuel Tank (L)235
Engine Oil changes (L)8
Coolant (L)30
Hydraulic System (L)220
Total transport length (mm)8480
Total transport width (mm)2550
Total transport height (mm)3150
Full cab height (mm)3150
Counterweight ground clearance (mm)1262
Wheelbase (mm)2550
Total tire outside width (mm)2550
Minimum ground clearance (mm)370
Back end turning radius (mm)2215
Maximum excavation radius (mm)8910
Maximum digging depth (mm)5590
Maximum excavation height (mm)10040
Maximum unloading height (mm)6950
Maximum vertical digging depth (mm)3720
see more

Overview

No.1085752

Brand Name:

Caterpillar

Model Number:

M315D

Year:

2011

Location:

Fujian China

Pub Date
