2011 Caterpillar M315D
Product Description
Commanding versatility meets operator-focused engineering in this 2011 Caterpillar M315D wheeled excavator, currently located in Kunming, Yunnan. Built for professionals who demand precision and productivity, this 15-ton machine delivers exceptional maneuverability with a compact 2215mm rear turning radius and impressive 34 km/h road speed. Powered by the reliable CAT C4.4 Acert engine producing 108 kW at 2000 rpm, operators benefit from responsive hydraulics and a 35 MPa main overflow pressure for confident digging performance.
- Superior visibility from the full cab positioned at 3150mm height, providing clear sightlines to all work zones
- Stable platform with 2550mm wheelbase and 370mm ground clearance for secure operation on varied terrain
- Intuitive controls backed by proven Caterpillar hydraulics (220L system capacity) for precise bucket placement
- Impressive reach specifications: 8910mm maximum excavation radius and 5590mm digging depth
- Multiple bucket configurations (0.78/0.34/1.1 m³) adapt to diverse applications
- Extended operational range with 235L fuel capacity minimizing downtime
Designed for operators who value comfort, control, and consist
| Specifications | Value |
|---|---|
| No. | 993494 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 17900 |
| Bucket capacity (m³) | 0.78/0.34/1.1 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CATERPILLAR C4.4 Acert |
| Rated power (kw/rpm) | 108(101)/2000 |
| Total displacement (L) | 4.4 |
| Forward speed (Km/h) | 34 |
| Rotation speed (rpm) | 10.5 |
| Main overflow set pressure (Mpa) | 35 |
| Fuel Tank (L) | 235 |
| Engine Oil changes (L) | 8 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 220 |
| Total transport length (mm) | 8480 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 3150 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1262 |
| Wheelbase (mm) | 2550 |
| Total tire outside width (mm) | 2550 |
| Minimum ground clearance (mm) | 370 |
| Back end turning radius (mm) | 2215 |
| Maximum excavation radius (mm) | 8910 |
| Maximum digging depth (mm) | 5590 |
| Maximum excavation height (mm) | 10040 |
| Maximum unloading height (mm) | 6950 |
| Maximum vertical digging depth (mm) | 3720 |
see more
Overview
No.993494
Brand Name：
CaterpillarModel Number：
M315DYear：
2011
Location：
Yunnan China
