2012 Caterpillar M315D
Product Description
Powered by the CATERPILLAR C4.4 Acert engine, delivering 108 kW at 2000 rpm, this 2012 Caterpillar M315D excavator ensures robust performance and reliability. With a total displacement of 4.4 liters, it offers efficient fuel consumption and reduced emissions. The hydraulic system, featuring a main overflow set pressure of 35 Mpa, provides precise control and high efficiency for demanding tasks.
- Working weight: 17,900 kg
- Bucket capacity: 0.78/0.34/1.1 m³
- Forward speed: 34 km/h
- Total transport dimensions: 8480 x 2550 x 3150 mm (LxWxH)
- Maximum excavation radius: 8910 mm
- Maximum digging depth: 5590 mm
- Maximum unloading height: 6950 mm
Engineered with a focus on durability and efficiency, the M315D is equipped to handle a wide range of construction and excavation projects. Its advanced hydraulics and powerful engine make it a top choice for operators seeking reliable and high-performance machinery.
| Specifications | Value |
|---|---|
| No. | 1002475 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 17900 |
| Bucket capacity (m³) | 0.78/0.34/1.1 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CATERPILLAR C4.4 Acert |
| Rated power (kw/rpm) | 108(101)/2000 |
| Total displacement (L) | 4.4 |
| Forward speed (Km/h) | 34 |
| Rotation speed (rpm) | 10.5 |
| Main overflow set pressure (Mpa) | 35 |
| Fuel Tank (L) | 235 |
| Engine Oil changes (L) | 8 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 220 |
| Total transport length (mm) | 8480 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 3150 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1262 |
| Wheelbase (mm) | 2550 |
| Total tire outside width (mm) | 2550 |
| Minimum ground clearance (mm) | 370 |
| Back end turning radius (mm) | 2215 |
| Maximum excavation radius (mm) | 8910 |
| Maximum digging depth (mm) | 5590 |
| Maximum excavation height (mm) | 10040 |
| Maximum unloading height (mm) | 6950 |
| Maximum vertical digging depth (mm) | 3720 |
see more
Overview
No.1002475
Brand Name：
CaterpillarModel Number：
M315DYear：
2012
Location：
Zhejiang China
Pub Date：
