2016 Caterpillar M315D
Product Description
Built on decades of engineering excellence, this 2016 Caterpillar M315D wheeled excavator delivers proven performance for demanding jobsites in Luzhou, Sichuan. Operating at 15 tons with a robust 17,900 kg working weight, this machine combines mobility with serious digging capability. Powered by the reliable CAT C4.4 Acert engine producing 108 kW at 2000 rpm, it offers exceptional fuel efficiency and consistent power delivery across all applications.
Caterpillar's reputation in the used equipment market remains unmatched. Parts availability through extensive dealer networks ensures minimal downtime, while strong resale values protect your investment long-term. This M315D features versatile bucket options (0.78/0.34/1.1 m³), impressive 8,910 mm maximum excavation radius, and 5,590 mm digging depth. With 34 km/h road speed and 10.5 rpm rotation, productivity stays high whether moving between sites or working in confined spaces.
- Maximum digging depth: 5,590 mm
- Maximum reach: 8,910 mm
- Hydraulic system capacity: 220 L
- Fuel tank: 235 L for extended operation
- Compact transport dimensions: 8,480 × 2,550 × 3,150 mm
Invest in proven reliability with genuine Caterpillar e
| Specifications | Value |
|---|---|
| No. | 1008244 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 17900 |
| Bucket capacity (m³) | 0.78/0.34/1.1 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CATERPILLAR C4.4 Acert |
| Rated power (kw/rpm) | 108(101)/2000 |
| Total displacement (L) | 4.4 |
| Forward speed (Km/h) | 34 |
| Rotation speed (rpm) | 10.5 |
| Main overflow set pressure (Mpa) | 35 |
| Fuel Tank (L) | 235 |
| Engine Oil changes (L) | 8 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 220 |
| Total transport length (mm) | 8480 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 3150 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1262 |
| Wheelbase (mm) | 2550 |
| Total tire outside width (mm) | 2550 |
| Minimum ground clearance (mm) | 370 |
| Back end turning radius (mm) | 2215 |
| Maximum excavation radius (mm) | 8910 |
| Maximum digging depth (mm) | 5590 |
| Maximum excavation height (mm) | 10040 |
| Maximum unloading height (mm) | 6950 |
| Maximum vertical digging depth (mm) | 3720 |
Overview
No.1008244
Brand Name：
CaterpillarModel Number：
M315DYear：
2016
Location：
Sichuan China
Pub Date：
