2016 Caterpillar M315D
Product Description
Secure proven performance without the premium price tag. This 2016 Caterpillar M315D wheeled excavator delivers 108kW of reliable power through its CATERPILLAR C4.4 Acert engine, offering exceptional value for operators seeking cost-effective productivity. Currently located in Dongguan, Guangdong, this 15-ton machine combines mobility with impressive reach capabilities—8910mm maximum excavation radius and 5590mm digging depth handle demanding jobsites with confidence.
- Working Weight: 17,900 kg with multiple bucket configurations (0.78/0.34/1.1 m³)
- Mobility Advantage: 34 km/h travel speed reduces transport costs between sites
- Operational Range: 10,040mm max excavation height, 6,950mm unloading height
- Hydraulic System: 35 MPa pressure, 10.5 rpm rotation speed for smooth operation
- Compact Footprint: 8,480mm transport length fits standard logistics
Invest smart. Acquire joint venture/import quality at a fraction of new equipment cost while maintaining the performance standards your projects demand. Ready for immediate deployment.
| Specifications | Value |
|---|---|
| No. | 1032896 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 17900 |
| Bucket capacity (m³) | 0.78/0.34/1.1 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CATERPILLAR C4.4 Acert |
| Rated power (kw/rpm) | 108(101)/2000 |
| Total displacement (L) | 4.4 |
| Forward speed (Km/h) | 34 |
| Rotation speed (rpm) | 10.5 |
| Main overflow set pressure (Mpa) | 35 |
| Fuel Tank (L) | 235 |
| Engine Oil changes (L) | 8 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 220 |
| Total transport length (mm) | 8480 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 3150 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1262 |
| Wheelbase (mm) | 2550 |
| Total tire outside width (mm) | 2550 |
| Minimum ground clearance (mm) | 370 |
| Back end turning radius (mm) | 2215 |
| Maximum excavation radius (mm) | 8910 |
| Maximum digging depth (mm) | 5590 |
| Maximum excavation height (mm) | 10040 |
| Maximum unloading height (mm) | 6950 |
| Maximum vertical digging depth (mm) | 3720 |
see more
Overview
No.1032896
Brand Name：
CaterpillarModel Number：
M315DYear：
2016
Location：
Guangdong China
Pub Date：
