2016 Caterpillar M315D
Product Description
Strengthen your fleet capacity with this 2016 Caterpillar M315D wheeled excavator, currently positioned in Guangdong Maoming and ready for immediate deployment. Powered by the proven C4.4 Acert engine delivering 108 kW at 2000 rpm, this 15-ton workhorse combines exceptional mobility with genuine Caterpillar engineering. With a maximum digging reach of 8,910 mm and excavation depth of 5,590 mm, it handles medium-duty applications across construction, utility, and infrastructure projects without compromising productivity.
- Working Weight: 17,900 kg – ideal for confined urban sites
- Multi-Bucket Configuration: 0.34/0.78/1.1 m³ capacity options for task versatility
- Road Speed: 34 km/h forward – rapid site-to-site transitions
- Compact Footprint: 2,550 mm transport width navigates restricted access zones
- Hydraulic Performance: 35 MPa system pressure, 10.5 rpm rotation speed
- Fuel Capacity: 235L tank extends operational intervals
Built for contractors requiring dependable backup equipment or expanding multi-machine operations, this M315D integrates seamlessly into existi
| Specifications | Value |
|---|---|
| No. | 1036749 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 17900 |
| Bucket capacity (m³) | 0.78/0.34/1.1 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CATERPILLAR C4.4 Acert |
| Rated power (kw/rpm) | 108(101)/2000 |
| Total displacement (L) | 4.4 |
| Forward speed (Km/h) | 34 |
| Rotation speed (rpm) | 10.5 |
| Main overflow set pressure (Mpa) | 35 |
| Fuel Tank (L) | 235 |
| Engine Oil changes (L) | 8 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 220 |
| Total transport length (mm) | 8480 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 3150 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1262 |
| Wheelbase (mm) | 2550 |
| Total tire outside width (mm) | 2550 |
| Minimum ground clearance (mm) | 370 |
| Back end turning radius (mm) | 2215 |
| Maximum excavation radius (mm) | 8910 |
| Maximum digging depth (mm) | 5590 |
| Maximum excavation height (mm) | 10040 |
| Maximum unloading height (mm) | 6950 |
| Maximum vertical digging depth (mm) | 3720 |
