2016 Caterpillar M315D
Product Description
Engineered for demanding excavation operations, this 2016 M315D wheeled excavator delivers exceptional performance through proven Caterpillar technology. Powered by the robust C4.4 ACERT engine generating 108 kW at 2000 rpm, this 15-ton machine combines a 4.4L displacement with a sophisticated hydraulic system operating at 35 MPa to provide precise control and consistent power delivery across all functions.
Technical specifications demonstrate superior operational capability:
- Maximum excavation reach of 8,910 mm with 5,590 mm digging depth
- Versatile bucket configurations: 0.78/0.34/1.1 m³ capacity options
- Road travel speed up to 34 km/h for efficient site-to-site mobility
- 220L hydraulic system capacity ensuring sustained performance
- 10.5 rpm rotation speed for productive cycle times
- Compact transport dimensions: 8,480 mm length × 2,550 mm width
Built to joint venture/import manufacturing standards, this M315D represents Caterpillar's commitment to engineering excellence. Currently located in Shenzhen, Guangdong, this machine offers proven reliability for contractors requiring a mobile, high-performance excavation solution with documented technical supe
| Specifications | Value |
|---|---|
| No. | 998201 |
| Tonnage (tons) | 15 |
| Working weight (kg) | 17900 |
| Bucket capacity (m³) | 0.78/0.34/1.1 |
| power | Traditional power |
| manufacturer | Joint venture/Import |
| bucket | backhoe |
| Engine type | CATERPILLAR C4.4 Acert |
| Rated power (kw/rpm) | 108(101)/2000 |
| Total displacement (L) | 4.4 |
| Forward speed (Km/h) | 34 |
| Rotation speed (rpm) | 10.5 |
| Main overflow set pressure (Mpa) | 35 |
| Fuel Tank (L) | 235 |
| Engine Oil changes (L) | 8 |
| Coolant (L) | 30 |
| Hydraulic System (L) | 220 |
| Total transport length (mm) | 8480 |
| Total transport width (mm) | 2550 |
| Total transport height (mm) | 3150 |
| Full cab height (mm) | 3150 |
| Counterweight ground clearance (mm) | 1262 |
| Wheelbase (mm) | 2550 |
| Total tire outside width (mm) | 2550 |
| Minimum ground clearance (mm) | 370 |
| Back end turning radius (mm) | 2215 |
| Maximum excavation radius (mm) | 8910 |
| Maximum digging depth (mm) | 5590 |
| Maximum excavation height (mm) | 10040 |
| Maximum unloading height (mm) | 6950 |
| Maximum vertical digging depth (mm) | 3720 |
Overview
No.998201
Brand Name：
CaterpillarModel Number：
M315DYear：
2016
Location：
Guangdong China
Pub Date：
